Impressivo
Movement detectors Timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Comfort switch Countdown timer
230V, IP20, for flush mounting, 2-wire or 3-wire models. User friendly timer with fixed time settings 15min,
Detection angle 170°. Detection range: frontal: 5 m, 30min, 1h, 2h, 4h or 8h. Countdown time is set with
lateral: 3 m. Operation also possible with 230V a screwdriver. 2-pole switch.
conventional push buttons. Brightness limit value:
0.5 Lux - 300 Lux. Switch-off delay: 1 to 10 min.
Mounting height: 0.8 m - 1.2 m. Includes insert and center plate
Includes insert and center plate white T210-84 2TKA00000875 1/10
Comfort switch, relay 10A, 3-wire connection anthracite T210-81 2TKA00000876 1/10
white 6816UC-84 2TKA00000478 1/10
aluminium T210-83 2TKA00000877 1/10
Sold in parts
Comfort switch insert, 40-300 W/VA, 2-wire connection Timer switches
6815U 2TKA001525G1 1/10 Timer switch display, 10 A. Four switching times per
day can be user-defined for each day of the week.
Comfort switch relay insert 10A, 3-wire connection Automatic summer/wintertime switch-over. 14-hour
6816U 2TKA001529G1 1/10 power reserve. Nominal voltage: 230 V/50 Hz.
Comfort switch sensor Operating temperature range: 0 °C - 35 °C. Timer switch
white 6815-84 2TKA001522G1 1/10 insert is connected to universal relay unit 6401U-102.
Comfort switch sensor Suitable center plates 6435-8X.
anthracite 6815-81 2TKA001520G1 1/10 Inserts
Comfort switch sensor Universal relay unit insert, 10 A
aluminium 6815-83 2TKA001521G1 1/10 6401U-102 2TKA001428G1 1/10
Timer switch display
11
Motion detector 180 Comfort multiple surveillance 6455-101-500 2TKA000025G1 1/10
230 V, 10 A relay, IP20, for flush mounting. Detection
area 180º. The area has been extended approximately Centre plates
35º downwards. This enables e.g. the surveillance of a white 6435-84 2TKA001434G1 1/10
stairway from an upper platform. The detection range
depends on the mounting height; for more information, aluminium 6435-83 2TKA001433G1 1/10
see the specifications. Adjustable lighting level
5 - 250 lux, switch-off delay 10sec-30min. Three-way
operating switch (off - automatic - always on), which
can be locked to the automatic position.
Sold in parts
Universal relay unit insert, 10 A
6401U-102 2TKA001428G1 1/10
Motion detector sensor 180 Comfort multiple
surveillance
white 6800-84-104M 2TKA001509G1 1/10
Motion detector sensor 180 Comfort multiple
surveillance
anthracite 6800-81-104M 2TKA001505G1 1/10
Motion detector sensor 180 Comfort multiple
surveillance
aluminium 6800-83-104M 2TKA001507G1 1/10

Motion detector 180 Comfort
230 V, 10 A relay, IP20, for flush mounting. Detection
area 180 degrees, approximately 8 m to the sides and
approximately 12 m to the front at the mounting
height. Adjustable lighting level 5-250 lux, switch-off
delay 2 sec.-30 min. Three-way operating switch
(off - automatic - always on), which can be locked to the
automatic position. Mounting height 1-1.2 m.
Sold in parts
Universal relay unit insert, 10 A
6401U-102 2TKA001428G1 1/10
Motion detector sensor 180 Comfort
white 6800-84-104 2TKA001508G1 1/10
Motion detector sensor 180 Comfort
anthracite 6800-81-104 2TKA001504G1 1/10
Motion detector sensor 180 Comfort
aluminium 6800-83-104 2TKA001506G1 1/10
