Impressivo
Dimmers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Flat LED-dimmer, with rotary control Sold in parts
Rotary control dimmer for LED lamps. Via mode switch DALI dimmer, with internal power supply, tunable white,
adjustable between leading edge control (RL) or trailing insert
edge control (RC). 2-wire connection (N-wire not needed).
Nominal power: 2 - 100 VA or 10-400W (details in manual). 2116/11U 2CKA006599A3026 1/10
Linear and low-noise operation. Mixed loads allowed. Dimmer center plate with neon lamp
Electronic short-circuit and overload protection. white 6540-84-102-510 2CKA006599A3035 1/10
Adjustable minimum brightness. Also applicable for Dimmer center plate, with neon lamp
1-gang 2-way installations. Nominal voltage
230 V/50-60 Hz. Maximum 20 LED lamps behind one anthracite 6540-81-102-510 2CKA006599A3035 1/10
dimmer. Compatibility with defined Philips LED lamps Dimmer center plate, with neon lamp
is guaranteed. aluminium 6540-83-102-510 2CKA006599A3036 1/10

DALI-potentiometrs
LED dimmer, rotary 2-100VA, with neon lamp
6523URCGL-84-103 2CKA006512A0347 1/10 For DALI broadcast service (via central telegram)
according standard IEC 62386. For switching and
LED dimmer, rotary 2-100VA, insert with neon lamp dimming up to 64 DALI- devices like electronic ballasts
6523UR-103-500 2CKA006512A0345 1/10 and transformers with DALI-interface. With
(2117/11U-500)or without (2117U-500) power supply.
Dimmer center plate, with neon lamp
white 6540-84-102-510 2CKA006599A3037 1/10 No center plate or frame included.
Dimmer center plate, with neon lamp Inserts
anthracite 6540-81-102-510 2CKA006599A3035 1/10 DALI potentiometer insert
2117U-500 2TKA00001861 1/10
Dimmer center plate, with neon lamp
aluminium 6540-83-102-510 2CKA006599A3036 1/10 With integrated power supply 11
Note! There might be limitations from transformer producers on how 2117/11U-500 2TKA00001865 1/10
many dimmable LED bulbs can be connected behind one transformer.
Dimmer center plate, with neon lamp
white 6540-84-102-510 2CKA006599A3037 1/10
Busch-rotary dimmer )
1
Flush-mounted, DALI, with internal power supply, anthracite 6540-81-102-510 2CKA006599A3035 1/10
tunable white aluminium 6540-83-102-510 2CKA006599A3036 1/10
For DALI broadcast service (via central telegram).
With integrated DALI power adaptor.
For switching and dimming up to 64 DALI- devices like Sold in parts
electronic ballasts and transformers with DALI-interface.
With rotary control and ON/OFF push operation. Dimmer, 60-600 VA, insert
For changing the colour temperature of "tunable white" lamps,
which meet DALI Standard IEC 62386-209 (Device Type 8).
Colour temperature can then be set between 2,700 K -
6,500 K.
With electronic short-circuit protection.
With electronic overload protection.
Brightness power-on level and backround brightness
level adjustable, buffered. 2250U 2TKA000723G1 1/10
With integrated LED illumination for orientation. Dimmer center plate, with neon lamp
Color of orientation light adjustable (18 presets and OFF). white 6540-84-102-510 2CKA006599A3037 1/10
Up to 5 potentiometers are connectable in parallel.
Up to 3 potentiometers are connectable in parallel in Dimmer center plate, with neon lamp
active mode. anthracite 6540-81-102-510 2CKA006599A3035 1/10
Not suitable for combining with other DALI sensors or
central units of other manufacturers. Dimmer center plate, with neon lamp
DALI-voltage: 15,5 V= aluminium 6540-83-102-510 2CKA006599A3036 1/10
Rated current: max. 75 mA
Power consumption: < 2,5 W
Number of DALI-units:
37 in case of one active power-potentiometer
in case of three active power-potentiometer in parallel
connection: 111
Active mode: the potentiometer is supporting the
necessary control circuit for other DALI-devices.
Passive mode: the potentiometer is suitable as additional
operation point.
Max. DALI-cable length: 300 m (1,5 - 2,5 mm²).
Without cover plate.
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz - 60 Hz
Protection class (Device): IP 20
Temperature range (Device): 0 °C to 35 °C
2116/11UJGL-84 2CKA006599A3031 1
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
