Millenium - Grid system for combination (AMD)
Triple rocker & KNX sensor frames Access control KNX

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Triple rocker switch/KNX sensors frame 1-gang Mifare transponder reader
Includes metal mounting frame 1) Access Control transponder reader able to be
Dimensions 86 x 86 mm. completely integrated into every KNX installation.
2) 1 binary input for connecting cardholder
3) 1 output 4A (24 V AC/DC)
Required additional power supply
(10…32 V DC/12…24 V AC)
Stainless Steel AMD5153-ST 2CLA637100N1101 10
Combination with frames AMD5144-XX & AMD5244-XX
Silk Black AMD5153-SB 2CLA637100N1501 10
TR/U 1.1 2CSY235683R2001 1
Antique Gold AMD5153-AG 2CLA637100N1601 10
Matt Gold AMD5153-MG 2CLA637100N1701 10
Mifare transponder holder
White Glass AMD5153-WG 2CLA637100N3001 10 Access Control transponder holder able to be
Black Glass AMD5153-BG 2CLA637100N3101 10 completely
integrated into every KNX installation.
1) 1 binary input (ON/OFF, dimmer, shutter)
Triple rocker switch/KNX sensors frame 2-gang 2) 1 output 4A (24 V AC/DC)
Includes metal mounting frame Required additional power supply (12…24 V AC/DC)
Dimensions 86 x 147 mm. Combination with frames AMD5144-XX & AMD5244-XX
TH/U 1.1 2CSY265232R2021 1

Stainless Steel AMD5253-ST 2CLA667200N1101 10 Set of 10 transponder cards
The transponder card uses passive transponder
Silk Black AMD5253-SB 2CLA667200N1501 10
technology operating in radio frequency (MIFARE
Antique Gold AMD5253-AG 2CLA667200N1601 10 technology), without the need for contact between the
11
Matt Gold AMD5253-MG 2CLA667200N1701 10 reader and the card itself.
The transponder card is read by swiping it in front of
White Glass AMD5253-WG 2CLA667200N3001 5
the reader at a maximum distance of 20 mm (can be
Black Glass AMD5253-BG 2CLA667200N3101 5 reduced according to installation environment).
TS/T 1 2CSY259412R2041 1
Software MiniMAC 4.1
Configuration and supervision software for ABB Access
Control system.
Special metal mounting plate for KNX Main functionalities are: management of keys, room
state monitoring.
sensors Guest check in/check out, front desk room load
monitoring, management of guest and employee
databases, front desk management of room climate, …
Special mounting plate KNX sensors 1G SW MiniMAC 4.1 2CSY258202R2051 1

AMD5053 2CLA627190N1001 6
