Millenium - Grid system for combination (AMD)
KNX system
Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty
2-Fold sensor Watchdog 180° flush mounted
Incl. 10 logic channels (light scene actuator, Movement sensor with up to four channels.
sequence actuator, logic gates, etc.). Detection range: frontal: 6 m., lateral: 6 m.
Control element: Switch contacts. Detection angle: 180 °.
Display elements: LED to indicate the function. Brightness limit value: 5 Lux - 150 Lux.
Protection class (Device): IP 20. Mounting height: 1.1 m.
Temperature range (Device): -5 °C to 45 °C. Protection class (Device): IP 20.
Dimensions: (L x W x D): 53 mm. x 44 mm. Temperature range (Device): -5 °C to 45 °C.
Dimensions: (L x W x D): 53 mm x 44 mm
AMD72053-AN Position for installation: vertical.
Anthracite (6125/20-981-500) 2CKA006115A0443 1
AMD72053-WP AMD70153-AN
White (6125/20-214-500) 2CKA006115A0500 1 Anthracite (6122/20-981-500) 2CKA006132A0306 1
AMD70153-WP
White (6122/20-214-500) 2CKA006132A0424 1
4-Fold sensor
Incl. 10 logic channels (light scene actuator,
sequence actuator, logic gates, etc.). Room thermostat heating/cooling fan coil
Control element: Switch contacts. Control element with room thermostat function for
Display elements: LED to indicate the function. triggering the heating, ventilation and fan-coil
Protection class (Device): IP 20. actuators.
Temperature range (Device): -5 °C to 45 °C. The controller is a thermostat for fan coil units in 2 -
Dimensions: (L x W x D): 53 mm. x 44 mm. and 4-pipe systems and conventional heating or
cooling systems.
AMD74053-AN The fan stage can be switched manually or in automatic
Anthracite (6126/20-981-500) 2CKA006116A0218 1
mode.
AMD74053-WP Incl. 10 logic channels (light scene actuator, sequence 11
White (6126/20-214-500) 2CKA006115A0501 1 actuator, logic gates, etc.).
Switch contacts for operating mode selection and dial
for setpoint or fan speed adjustment.
6-Fold sensor Display elements: LCD showing operation modes.
Incl. 10 logic channels (light scene actuator, Protection class (Device): IP 20.
sequence actuator, logic gates, etc.). Temperature range (Device): -5 °C to 45 °C.
Control element: Switch contacts. Dimensions: (L x W x D): 53 mm. x 44 mm.
Display elements: LED to indicate the function.
Protection class (Device): IP 20. AMD70053-AN
Temperature range (Device): -5 °C to 45 °C. Anthracite (6124/08-981-500) 2CKA006134A0309 1
Dimensions: (L x W x D): 53 mm. x 44 mm. AMD70053-WP
AMD76053-AN White (6124/08-214-500) 2CKA006134A0354 1
Anthracite (6129/20-981-500) 2CKA006118A0104 1
AMD76053-WP Ceiling light symbol
White (6129/20-214-500) 2CKA006115A0502 1 Blind symbol
Scene symbol
Temperature symbol
6-Fold sensor with IR Light symbol
Incl. 10 logic channels (light scene actuator, Fan coil symbol
sequence actuator, logic gates, etc.). Labelling insert for Millenium control covers
Control element: Switch contacts. 1 /2-gang, 2 / 4-gang, 3 / 6-gang and 3 / 6-gang
Display elements: LED to indicate the function. with infrared
Protection class (Device): IP 20.
Temperature range (Device): -5 °C to 45 °C. AM50701-GR
Dimensions: (L x W x D): 53 mm. x 44 mm. (6123/20-500) 2CKA006123A0001 10
AMD76153-AN AM50702-GR
Anthracite (6129/21-981-500) 2CKA006118A0107 1 (6123/21-500) 2CKA006123A0002 10
AMD76153-WP AM50703-GR
White (6129/21-214-500) 2CKA006134A0355 1 (6123/22-500) 2CKA006123A0003 10
AM50704-GR
(6123/23-500) 2CKA006123A0004 10
AM50705-GR
(6123/24-500) 2CKA006123A0005 10
AM50706-GR
(6123/26-500) 2CKA006123A0006 10
