11/682 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Movement detector
Busch-Watchdog flush-mounted /
sensors

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Watchdog 180 flush-mounted comfort Busch-Watchdog 180 flush-mounted comfort sensor II
1
sensor II ) ) for All Weather 44 ) )
1
2
2
with multi-lens with combi-lens
For automatic switching of devices dependent on For automatic switching of devices dependent on
motion and brightness. motion and brightness.
For down-to-ground detection. For use outdoors.
For relay inserts 6401 U-102, 6402 U and 6812 U-101. For down-to-ground detection.
For MOS-Fet insert 6804 U-101. For Busch-Universal relay switch insert 6401 U-102.
For Dimmer insert 6593 U. IP 44 only in conjunction with cover frames
For extension insert 6805 U. All Weather 44.
With integrated selector switch for ON-AUTOMATIC-OFF Surveillance density: 40 sectors with 160 switching
(lockable). segments.
Soft phase-out: In combination with the 6593 U (mode Switch-off delay: 10 sec to 30 min or short-time pulse
of operation: Soft OFF) the illumination is dimmed 1 sec adjustable.
down within 60 sec and switched off. With screw-type terminal.
Surveillance density: 28 sectors with 112 switching Detection range: frontal: 15 m, lateral: 10 m, Mounting
segments. height: 2.5 m
Switch-off delay: 10 sec to 30 min or short-time pulse Detection range 2: frontal: 9 m, lateral: 4 m, Mounting
1 sec adjustable. height: 1.2 m
Detection range: frontal: 15 m, lateral: 5 m, Mounting Detection angle: 180 °
height: 2.5 m Brightness limit value: 5 Lux Up to daytime operation
Detection range 2: frontal: 10 m, lateral: 2.5 m, Mounting Mounting height: 0.8 m - 1.2 m alternative: 2.5 m
height: 1.2 m Protection class (Sensor): IP 44
Detection angle: 180 ° Temperature range (Device): -25 °C to 55 °C
Brightness limit value: 5 Lux Up to daytime operation Position for installation: vertical
Mounting height: 0.8 m - 1.2 m alternative: 2.5 m brown 6800-31-102C 2CKA006800A2353 1
Protection class (Sensor): IP 20
11
Temperature range (Device): 0 °C to 35 °C white 6800-32-102C 2CKA006800A1898 1
aluminium 6800-33-102C 2CKA006800A2354 1
silver
future® linear
alpine white 6800-34-102C 2CKA006800A1674 1
anthracite 6800-81-104M 2CKA006800A2269 1
anthracite 6800-35-102C 2CKA006800A1740 1
ivory white 6800-82-104M 2CKA006800A2100 1
1) Delivered with sealing ring.
aluminium 6800-83-104M 2CKA006800A2327 1 2) Please order the respective flush-mounted insert separately.
silver )
3
studio white 6800-84-104M 2CKA006800A2102 1/10 RC suppressor
studio white, 6800-884-104M 2CKA006800A2498 1 For protection against the damage or destruction of
matt ) electronic devices due to overvoltages.
3
For wiring network-interconnected inductivities (e.g..
black matt ) 6800-885-104M 2CKA006800A2500 1
3
relay, protection, fluorescent lamps, transformers, etc.).
Eliminates functional disturbances on electronic
solo®
devices, e.g. automatic circuit reclosure (clocking) of a
ivory white 6800-82-104M 2CKA006800A2100 1 movement detector.
studio white 6800-84-104M 2CKA006800A2102 1/10 Dimensions: diameter 25 mm, length 35 mm, length of
the connecting cable approx. 100 mm.
grey metallic ) 6800-803-104M 2CKA006800A2485 1
3
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz
Busch-axcent®
6899 2CKA006899A0231 10
anthracite 6800-81-104M 2CKA006800A2269 1
studio white 6800-84-104M 2CKA006800A2102 1/10
black matt ) 6800-885-104M 2CKA006800A2500 1
3
carat®
anthracite 6800-81-104M 2CKA006800A2269 1
ivory white 6800-82-104M 2CKA006800A2100 1
studio white 6800-84-104M 2CKA006800A2102 1/10
pure stainless steel
stainless steel 6800-866-104M 2CKA006800A2344 1
1) installation: slide switch top.
2) Please order the respective flush-mounted insert separately.
3) Surface painted.
