11/680 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Movement detector
Busch-Watchdog presence inserts

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Busch-Watchdog extension insert ) Busch-touch dimmer ) ) ) ) ) )
6
5
2
1
4
3
3 wire connection (neutral conductor required). Flush-mounted, LED, 2-100 W
For extending Busch-Watchdog 180 flush-mounted and Touch dimmer.
Busch-Watchdog Presence tech installations. 2-wire connection (neutral conductor not required)
For combination with relay insert 6401 U-102 and Neutral conductor optionally connectable
6402 U. (recommended for the connection of low loads
For combination with MOS-Fet insert 6804 U-101. < 10 W/VA).
For combination with Dimmer insert 6593 U and Optimised for dimming of retrofit LED lamps (LEDi).
6550 U-101. For incandescent lamps, 230V tungsten halogen lamps
For Busch-Watchdog 180 flush-mounted sensor and low-voltage halogen lamps with conventional
Comfort II 6800-xxx-104 and 6800-xxx-104M. transformers or electronic transformers and dimmable
For Busch-Watchdog Presence tech 6813-xxx-101 und halogen energy-saving lamps.
6813/11-xxx. Mix operaton of LEDi with conventional loads possible.
Rated voltage: 230 V~, +10 % / -10 % With adjustable minimum brightness.
Rated frequency: 50 Hz The minimum brightness for the leading edge control
Control/Signal outputs: 1, electronic output, potential- can be adjusted using the potentiometer.
bound The potentiometer at the left limit stop corresponds
Temperature range (Device): 0 °C to 35 °C with the trailing edge control mode.
Low-noise level by MOSFET transistors.
6805 U-500 2CKA006800A2161 1/10
With electronic short-circuit protection.
Mounting 35 mm deep flush 1gang With electronic overload protection.
boxes: or Dual Box 3070-2/35 BSDB. With light-level memory and minimum brightness
Cover frames: 1gang frame 1721 BS-2xG memory.
or Dual Box frame 1722 BSDB-2xG. Operation also possible via conventional push buttons
(2020 US, 2021/6 UK).
2gang product 2gang combination with adapter plate Without control cover.
combinations: APBS in Dual Box only.
For control cover with control lamp 6543-xxx-10x.
11
1) Not combinable with relay switch insert 6812 U-101.
For Busch-Remote control IR control cover 6066-xxx-10x.
For comfort timer control element 6455-101-500.
For Busch-Watchdog Presence tech 6813-xxx-101 und
2
1
4
3
Busch-touch dimmer ) ) ) ) 6813/11-xxx.
flush mounted, RLC, 60-420 W Nominal power: 2 - 100 W/VA (retrofit LED loads).
With light-level memory and intelligence for universal Nominal power: 10 - 200 W/VA (non-LED loads).
operation. Rated voltage: 230 V~, +10 % / -10 %
Selectable Soft-ON/OFF function and memory function. Rated frequency: 50 Hz - 60 Hz
Capacity expansion via output-side, parallel connectable Protection class (Device): IP 20
load line with a power module 6594 U up to 735 W/VA Temperature range (Device): 0 °C to 35 °CIEC 60669-2-1,
possible. British Standard EN 60669-2-1
For incandescent lamps, 230 V tungsten halogen lamps
and low-voltage halogen lamps with conventional
transformers or electronic transformers.
Short-circuit-proof, overload-protected. 6526 U-500 2CKA006512A0323 1/10
With touch control. 1) Illuminable with neon lamp. Neon lamp included in delivery with cover plate.
Operation also possible via conventional push buttons 2) In the case of conventional transformers, take ~20% transformer loss into account.
(2020 US, 2021/6 UK). 3) In case of electronic transformers, 5 % transformer losses.
Without control cover. 4) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
For control cover with control lamp 6543-xxx-10x. Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
For Busch-Remote control IR control cover 6066-xxx-10x. 5) Recommendation: Please use loads and types of one producer.
For comfort timer control element 6455-101-500. 6) In connection with 6810-21x-101 and 6800-xx-104 (M) only suitable for switching
For Busch-Watchdog 180 flush-mounted Sensor retrofit LEDs (for 2-conductor connection).
Standard 6810-21x-101.
For Busch-Watchdog 180 flush-mounted sensor
Comfort II 6800-xxx-104 and 6800-xxx-104M.
For Busch-Watchdog Presence tech 6813-xxx-101 und
6813/11-xxx.
Combinable with Busch-Watchdog extension insert
6805 U.
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz
Rated power: 60 - 420 W/VA
IEC 60669-2-1, British Standard EN 60669-2-1

6593 U-500 2CKA006590A0171 1/10
1) In the case of conventional transformers, take ~20% transformer loss into account.
2) In case of electronic transformers, 5 % transformer losses.
3) In conjunction with 6800-xxx-104 (M) a Soft Off can be adjusted.
4) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
