Movement detector
Presence detector

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Busch-Presence detector Corridor premium KNX ) ) Busch-Watchdog Sky KNX )
1
2
30 meters 24 meters
Detection range: rectangular. Detection range (for mounting height 6 m and 12 m):
For mounting height of 3 m: frontal toward the detector circular.
at a max. of 20 m x 3 m (at a max. of 10 m x 3 m per Walking persons Ø: max. 18 m and 24 m.
side). Crosswise toward the detector at a max. of 30 m x Visible height 23 mm. With 2 channels.
3 m (max. of 15 m x 3m per side). Targeted for connection and disconnection of lights
With integrated KNX bus coupler. bands depending on the room brightness.
Mounting height 27 mm. Use of the device as a movement detector.
With 4 channels. Detectors application with 2 power off stages.
For dimming/brightness of the rules to a defined value Detectors application with integrated monitoring
in a designated collection area. function. Constant light switch with up to two
HVAC function for controlling heating and/or cooling independent channels. Constant light switch with max.
systems and ventilation systems in the designated 2 outputs for brightness-dependent switching of two
collection area. light bands in the area. With integrated KNX bus coupler.
Detectors application with 2 power off stages. The programming button can be activated with the IR
Detectors application with integrated monitoring transmitter 6010-25 (-500).
function. Suitable for false ceilings with a board thickness from
Constant light controller with up to two independent 9 to 25 mm.
channels. Hole size: Ø 68 mm.
Constant light controller with max. 2 outputs for Suitable for surface mounting installation.
dimming daylight control/rules of two rooflights in the Cannot be installed in British Standard or VDE
room. flushmounted box.
Integrated object room temperature controller. Recommendation: Installation housing from Kaiser
10 freely programmable IR channels (blue and/or white) HaloX-O (Art.no. 1290-40) with corresponding cover
Incl. 5 logic channels (logic gates, gates, delay and plates (1290-47 or 1290-85 for fair faced concrete) or
staircase lighting) IBTronic H120-68 from Spelsberg. 11
Evaluation via internal brightness sensor. Connections:
Weighting of up to 2 external brightness values and the KNX-line: Bus connection terminal

internal brightness sensor possible. Brightness limit value: 1 Lux - 1000 Lux
The programming button can be activated with the IR Mounting height: 4 m - 12 m
transmitter 6010-25 (-500). Protection class (Device): IP 20
Ceiling mounting on suspended ceilings with spring Temperature range (Device): -5 °C to 45 °C
clamps, on solid ceilings in surface-mounting boxes Dimensions: (L x W x D): 91 mm x 91 mm x 45 mm
6131/39-xxx(-500) or on VDE flush-mounted boxes Mounting depth: 22 mm
with intermediate ring for VDE flush-mounted boxes studio white 6131/40-24-500 2CKA006132A0350 1
6131/38-xxx(-500). matt
Suitable for false ceilings with a board thickness from
9 to 25 mm. 1) For software and description please check the current Online-Catalogue.
Hole size: Ø 68 mm.
Cannot be installed in British Standard or VDE Surface-mounting box
flushmounted box. For Busch-Presence detector mini KNX
Recommendation: Installation housing from Kaiser For installing a Busch-Presence detector mini KNX
HaloX-O (Art.no. 1290-40) with corresponding cover 6131/20-xxx(-500) or a Busch-Presence detector mini
plates (1290-47 or 1290-85 for fair faced concrete) or premium KNX 6131/21-xxx(-500).
IBTronic H120-68 from Spelsberg. Protection class (Device): IP 20
Connections: Dimensions: (L x W x D): 80 mm x 80 mm x 35 mm
KNX-line: Bus connection terminal
Brightness limit value: 1 Lux - 1000 Lux aluminium 6131/29-183-500 2CKA006132A0352 1
Mounting height: 2 m - 4 m silver
Protection class (Device): IP 20 studio white 6131/29-24-500 2CKA006132A0351 1
Temperature range (Device): -5 °C to 45 °C matt
Dimensions: (L x W x D): 91 mm x 91 mm x 49 mm
Mounting depth: 22 mm
Surface-mounting box
studio white 6131/51-24-500 2CKA006132A0413 1 For Busch-Presence detector KNX, Busch-Watchdog
matt
Sky KNX and Busch-Presence detector Corridor KNX
studio white 6131/51-24-508 2CKA006131A0058 1 For mounting a Busch-Presence detector KNX 6131/30-
matt xxx(-500), a Busch-Presence detector Premium KNX
aluminium 6131/51-183-500 2CKA006132A0414 1 6131/31-xxx(-500), a Busch-Presence detector Corridor
silver KNX 6131/50-xxx(-500), a Busch-Presence detector
Corridor premium KNX 6131/51-xxx(-500) or a Busch-
1) For software and description please check the current Online-Catalogue.
2) HVAC = Heating/ ventilation/air-conditioning Watchdog Sky KNX 6131/40-24(-500).
Protection class (Device): IP 20
Dimensions: (L x W x D): 91 mm x 91 mm x 33 mm
aluminium 6131/39-183-500 2CKA006132A0354 1
silver
studio white 6131/39-24-500 2CKA006132A0353 1
matt
