11/679

—
Movement detector
Busch-Watchdog presence inserts

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

6
1
5
3
Universal-Slave insert Busch-Watchdog MOS-Fet Insert ) ) ) ) ) )
2
4
3 wire connection (neutral conductor required). 2-wire connection (neutral conductor not required)
For the extension of Busch-Comfort switch or Busch- For Busch-Watchdog 180 flush-mounted Sensor
Presence detector installations. Standard 6810-21x-101.
For communication with Universal relay insert For Busch-Watchdog 180 flush-mounted sensor
6440/01 U-500. Comfort II 6800-xxx-104 and 6800-xxx-104M.
For communication with Universal-e-contact insert For Busch-Watchdog Presence tech 6813-xxx-101 und
6440/04 U-500. 6813/11-xxx.
For Busch-Comfort switch control element Combinable with Busch-Watchdog extension insert
6815-...-101-500. 6805 U.
For Busch-Presence detector sensor 6813-…-102-500. Operation also possible via conventional push buttons
Rated voltage: 230 V~, +10 % / -10 % (2020 US, 2021/6 UK).
Rated frequency: 50 Hz - 60 Hz Rated voltage: 230 V~, +10 % / -10 %
Control/Signal outputs: 1, electronic output, potential- Rated frequency: 50 Hz
bound Suitable for: 230 V incandescent lamps, 230 V halogen
Temperature range (Device): -5 °C to 45 °C lamps and low-voltage halogen lamps with conventional
Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm transformers or Busch Electronic Transformer.
Mounting depth: 31 mm Rated power: 60 - 420 W/VA
Temperature range (Device): 0 °C to 35 °CBritish
6440/05 U-500 2CKA006400A0091 1
Standard EN 60669-2-1

Busch-Universal relay switch insert
3 wire connection (neutral conductor required). 6804 U-101-500 2CKA006800A2219 1/10
For Busch-Watchdog 180 flush-mounted Sensor 1) In case of electronic transformers, 5 % transformer losses.
2) In the case of conventional transformers, take ~20% transformer loss into account.
Standard 6810-21x-101.
3) Not suitable for the activation of energy-saving lamps, conventional and electronic
For Busch-Watchdog 180 flush-mounted sensor ballast units and LED lamps. 11
Comfort II 6800-xxx-104 and 6800-xxx-104M. 4) Not suitable for activating the staircase time delay.
For Busch-Watchdog 180 FP sensor for All Weather 44 5) Cannot be used to control relais.
6800-3x-102C. 6) Requires an NIS international socket, E-No. 372507676.
For Busch-Watchdog Presence tech 6813-xxx-101 und
6813/11-xxx.
For comfort timer control element 6455-101-500. Busch-Universal 2gang 1way insert
For Busch-Remote control IR control cover 6067-xxx-10x. 3 wire connection (neutral conductor required).
For control cover with control lamp 6543-xxx-10x. For the serial switch operating mode: 2 separate
Combinable with Busch-Watchdog extension insert outputs, 2 separate extension inputs.
6805 U. For operation mode timer: output 1 (eg lighting), output
Operation also possible via conventional push buttons 2: ON/Off delay in dependence of output 1 (eg fan
(2020 US, 2021/6 UK). control).
Rated voltage: 230 V~, +10 % / -10 % For Busch-Watchdog 180 flush-mounted Sensor
Rated frequency: 50 Hz Standard 6810-21x-101.
Outputs: 1x Normally open contact, potential-bound For Busch-Watchdog 180 flush-mounted sensor
Suitable for: 230 V incandescent lamps, 230 V halogen Comfort II 6800-xxx-104 and 6800-xxx-104M.
lamps, fluorescent lamps and low-voltage halogen For Busch-Watchdog Presence tech 6813-xxx-101 und
lamps, that are operated via transformers. 6813/11-xxx.
Rated current: 10 AX For Busch-Remote control IR control cover 6066-xxx-10x
Rated power: 2300 W/VA and 6067-xxx-10x.
Temperature range (Device): -25 °C to 55 °C60669-2-1 For control cover 6430-xxx-10x and 6543-xxx-10x.
Combinable with Busch-Watchdog extension insert
6805 U.
6401 U-102-500 2CKA006401A0049 1/10 Operation also possible via conventional push buttons
(2020 US, 2021/6 UK).
Busch-Watchdog relay mechanism Rated voltage: 230 V~, +10 % / -10 %
3 wire connection (neutral conductor required). Rated frequency: 50 Hz
For Busch-Watchdog 180 flush-mounted Sensor Outputs: 2x Normally open contact, potential-bound
Standard 6810-21x-101. Suitable for: 230 V incandescent lamps, 230 V halogen
For Busch-Watchdog 180 flush-mounted sensor lamps, fluorescent lamps and low-voltage halogen
Comfort II 6800-xxx-104 and 6800-xxx-104M. lamps, that are operated via transformers.
For Busch-Watchdog Presence tech 6813-xxx-101 und Rated current: 10 AX
6813/11-xxx. Rated power: 2300 W/VA
Rated voltage: 230 V, +10 % / -10 % Temperature range (Device): 0 °C to 35 °CBritish
Rated frequency: 50 Hz Standard EN 60669-2-1
Outputs: 1x Normally open contact, potential-bound
Suitable for: 230 V incandescent lamps, 230 V halogen 6402 U-500 2CKA006401A0051 1/10
lamps, fluorescent lamps and low-voltage halogen
lamps, that are operated via transformers. Mounting 35 mm deep flush 1gang
Rated power: 700 W/VA boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
Temperature range (Device): 0 °C to 55 °CBritish combinations: APBS in Dual Box only.
Standard EN 60669-2-1
neon indicator: neon lamp 3855, one neon lamp is supplied together with
control cover plates 6540-2x.
6812 U-101-500 2CKA006800A2160 1/10
