Movement detector
Busch-Watchdog presence inserts Busch-Watchdog flush-mounted /
sensors

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-touch dimmer ) ) ) Busch-Watchdog 180 flush-mounted comfort
1
2
3
1
flush mounted, 1-10V sensor II )
3 wire connection (neutral conductor required). with select-lens
For controlling ballast units for fluorescent lamps with For automatic switching of devices dependent on
control output 1-10 V DC, control current max. 50 mA DC. motion and brightness.
For control cover with control lamp 6543-xxx-10x. For relay inserts 6401 U-102, 6402 U and 6812 U-101.
For Busch-Remote control IR control cover 6066-xxx-10x For MOS-Fet insert 6804 U-101.
and 6067-xxx-10x. For Dimmer insert 6593 U.
For comfort timer control element 6455-101-500. For extension insert 6805 U.
For Busch-Watchdog 180 flush-mounted Sensor With integrated selector switch for ON-AUTOMATIC-OFF
Standard 6810-21x-101. (lockable).
For Busch-Watchdog 180 flush-mounted sensor Soft phase-out: In combination with the 6593 U (mode
Comfort II 6800-xxx-104 and 6800-xxx-104M. of operation: Soft OFF) the illumination is dimmed
For Busch-Watchdog Presence tech 6813-xxx-101 und down within 60 sec and switched off.
6813/11-xxx. Surveillance density: 18 sectors with 72 switching
Combinable with Busch-Watchdog extension insert segments.
6805 U. Switch-off delay: 10 sec to 30 min or short-time pulse
Operation also possible via conventional push buttons 1 sec adjustable.
(2020 US, 2021/6 UK). Detection range: frontal: 12 m, lateral: 8 m
For LED control via control gears Detection angle: 180 °
Without control cover. Brightness limit value: 5 Lux Up to daytime operation
Rated voltage: 230 V~, +10 % / -10 % Mounting height: 0.8 m - 1.2 m
Rated frequency: 50 Hz Protection class (Sensor): IP 20
Rated power: 700 W/VA Temperature range (Device): 0 °C to 35 °C
IEC 60669-2-1, British Standard EN 60669-2-1
11
future® linear
6550 U-101-500 2CKA006550A0042 1
anthracite 6800-81-104 2CKA006800A2268 1
1) Non-illuminable.
2) Only in conjunction with standard flush-mounting boxes according to DIN 49073, ivory white 6800-82-104 2CKA006800A2099 1/10
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall aluminium 6800-83-104 2CKA006800A2325 1
or 3060 wallbox concrete)
3) with integrated making-current limiter silver ) 2
studio white 6800-84-104 2CKA006800A2101 1/10
studio white, 6800-884-104 2CKA006800A2497 1
matt ) 2
black matt ) 2 6800-885-104 2CKA006800A2506 1
solo®
ivory white 6800-82-104 2CKA006800A2099 1/10
studio white 6800-84-104 2CKA006800A2101 1/10
grey metallic ) 2 6800-803-104 2CKA006800A2484 1
Busch-axcent®
anthracite 6800-81-104 2CKA006800A2268 1
studio white 6800-84-104 2CKA006800A2101 1/10
black matt ) 2 6800-885-104 2CKA006800A2506 1
carat®
anthracite 6800-81-104 2CKA006800A2268 1
ivory white 6800-82-104 2CKA006800A2099 1/10
studio white 6800-84-104 2CKA006800A2101 1/10
pure stainless steel
stainless steel 6800-866-104 2CKA006800A2343 1
1) Please order the respective flush-mounted insert separately.
2) Surface painted.
