ABB i-bus® KNX
Outputs – Combi Switch Actuators

Switching/Shading Actuator, 6 A, MDRC NEW
The compact 6 A combi switch actuator has 8, 16 or 24 independent switching relays.
The outputs can be used individually via ABB i-bus® KNX for switching electrical loads or
in pairs for controlling 230 V AC roller shutter or blind drives (no electromechanically inter-
locking). The device features a manual operation, which can also be disabled. Via the manual
operation the outputs can be operated manually and the switching or driving status is dis-
played. The device is powered by KNX and requires no additional power supply.

SAH/S 8.6.7.1
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
8-fold 4 SAH/S 8.6.7.1 2CDG110244R0011 0.35 1
16-fold 8 SAH/S 16.6.7.1 2CDG110245R0011 0.60 1
24-fold 12 SAH/S 24.6.7.1 2CDG110246R0011 0.83 1

Switching/Shading Actuator, 10 A, MDRC NEW
The compact 10 A combi switch actuator has 8, 16 or 24 independent switching relays.
The outputs can be used individually via ABB i-bus® KNX for switching electrical loads or
in pairs for controlling 230 V AC roller shutter or blind drives (no electromechanically inter-
locking). The device features a manual operation, which can also be disabled. Via the manual
operation the outputs can be operated manually and the switching or driving status is dis-
played. The device is powered by KNX and requires no additional power supply.

SAH/S 16.10.7.1 Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
8-fold 4 SAH/S 8.10.7.1 2CDG110247R0011 0.35 1
16-fold 8 SAH/S 16.10.7.1 2CDG110248R0011 0.60 1
24-fold 12 SAH/S 24.10.7.1 2CDG110249R0011 0.83 1

14
Switching/Shading Actuator, 16 A, MDRC NEW
The compact 16 A combi switch actuator has 8, 16 or 24 independent switching relays.
The outputs can be used individually via ABB i-bus® KNX for switching electrical loads or
in pairs for controlling 230 V AC roller shutter or blind drives (no electromechanically inter-
locking). The device features a manual operation, which can also be disabled. Via the manual
operation the outputs can be operated manually and the switching or driving status is dis-
played. The device is powered by KNX and requires no additional power supply.
SAH/S 24.16.7.1
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
8-fold 4 SAH/S 8.16.7.1 2CDG110250R0011 0.35 1
16-fold 8 SAH/S 16.16.7.1 2CDG110251R0011 0.60 1
24-fold 12 SAH/S 24.16.7.1 2CDG110252R0011 0.83 1
