ABB i-bus® KNX
Outputs

Switch Actuator, 16/20 AX, C-Load, MDRC to be discontinued
Uses floating contacts to switch independent electrical loads via ABB i-bus® KNX. Every out-
put can be operated manually and features display of the switching state. The 16 AX-AC3,
C-Load devices are especially suited for switching loads with high surge currents such as
luminaries with ballasts or fluorescent lighting (AX) according to EN 60669.

Description Mod. Order details Price Weight Pack
SA/S 12.16.5.1
width 1 piece 1 piece unit
Type code Order code kg pc.
2-fold 2 SA/S 2.16.5.1 2CDG110132R0011 0.19 1
4-fold 4 SA/S 4.16.5.1 2CDG110133R0011 0.31 1
8-fold 8 SA/S 8.16.5.1 2CDG110134R0011 0.59 1
12-fold 12 SA/S 12.16.5.1 2CDG110137R0011 0.85 1

Switch Actuator, 16/20 AX, C-Load with Current Detection, MDRC to be discontinued
Switches with floating contacts, 2, 4, 8 or 12 independent electrical loads with high surge
currents. The Switch Actuators feature a circuit for high precision current detection for each
output that is used to monitor the connected circuits. Every output can be operated manu-
ally and features display of the switching state. The 16/20A, C-Load devices are especially
suited for switching loads with high surge currents such as luminaries with ballasts or
fluorescent lighting (AX) according to EN 60669.
SA/S 8.16.6.1
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
2-fold 2 SA/S 2.16.6.1 2CDG110112R0011 0.21 1
4-fold 4 SA/S 4.16.6.1 2CDG110113R0011 0.38 1
8-fold 8 SA/S 8.16.6.1 2CDG110114R0011 0.69 1
12-fold 12 SA/S 12.16.6.1 2CDG110138R0011 0.90 1
