14/40 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB i-bus® KNX
Outputs

Switch Actuator, 6 A, MDRC to be discontinued
Using floating contacts it switches 4, 8 or 12 independent electrical loads. The 6 A-AC3
devices are suited for switching resistive, inductive and capacitive loads. Please note:
Increased module width compared to previous generation.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
SA/S 8.6.1.1
Type code Order code kg pc.
4-fold 4 SA/S 4.6.1.1 2CDG110152R0011 0.18 1
8-fold 6 SA/S 8.6.1.1 2CDG110153R0011 0.27 1
12-fold 8 SA/S 12.6.1.1 2CDG110154R0011 0.35 1

Switch Actuator with manual Operation, 6 A, MDRC to be discontinued
Switches 2, 4, 8 and 12 independent electrical loads using floating contacts. Every output
can be operated manually and features display of the switching state. The 6 A-AC3 devices
are suited for switching resistive, inductive and capacitive loads.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
SA/S 8.6.2.1
Type code Order code kg pc.
2-fold 2 SA/S 2.6.2.1 2CDG110180R0011 0.18 1
4-fold 4 SA/S 4.6.2.1 2CDG110181R0011 0.29 1
8-fold 8 SA/S 8.6.2.1 2CDG110182R0011 0.51 1
12-fold 12 SA/S 12.6.2.1 2CDG110183R0011 0.74 1

Switch Actuator, 10 AX, MDRC to be discontinued
Switches 2, 4, 8 and 12 independent electrical loads using floating contacts.
Every output can be operated manually and features display of the switching state.
The 10 AX-AC1 devices are especially suited for switching resistive, inductive and capacitive
14
loads such as fluorescent lighting (AX) compliant to EN 60669.
Description Mod. Order details Price Weight Pack
SA/S 4.10.2.1 width 1 piece 1 piece unit
Type code Order code kg pc.
2-fold 2 SA/S 2.10.2.1 2CDG110155R0011 0.18 1
4-fold 4 SA/S 4.10.2.1 2CDG110156R0011 0.29 1
8-fold 8 SA/S 8.10.2.1 2CDG110157R0011 0.51 1
12-fold 12 SA/S 12.10.2.1 2CDG110158R0011 0.74 1
