ABB i-bus® KNX
Outputs

Switch Actuator, 1-fold, 16 A, FM
For switching 230 V~ consumers. Equipped with two extension inputs which depending on
parameterization can act directly on the switching output or alternatively as binary inputs
on the KNX bus. One Normally open contact, potential free; switching voltage: 230 V AC;
50/60 Hz; max. switching current: 16 A; switching capacity: up to 2.500 W depending on the
consumer. Rated voltage: 230 V~, +10% / –10%, 50 Hz – 60 Hz. The bus can be connected via
6151/11 U-500 enclosed terminal block.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
– 6151/11 U-500 2CKA006151A0245 0.11 1

I/O Actuator, 6 A, MDRC
For the control of loads in residential areas, typically in hotel rooms and apartments.
The I/O Actuators provide binary inputs for the connection of conventional push-buttons
and outputs for switching loads. Inputs and outputs can be internally connected by ETS.
By integrating the devices into KNX networks further functions can be realised: e.g. central
control or room based emergency calls to a control centre.

IO/S 4.6.1.1 Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
4-fold 4 IO/S 4.6.1.1 2CDG110168R0011 0.17 1
8-fold 8 IO/S 8.6.1.1 2CDG110169R0011 0.30 1

Analogue Actuator
The Analogue Actuators convert KNX telegrams in voltage or current signals. These
analogue output signals are used to influence regulatory processes. For example, devices
14
for heating, air conditioning or ventilation applications can be adjusted in their operation
depending on the information, which are transmitted via the bus system. The Analogue
Actuators are available in a 4-fold DIN rail version and a 2-fold device with surface
mounting housing. The ABB i-bus® Tool is supported for advanced diagnosis and improved
commissioning.
AA/S 4.1.2
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
4-fold, MDRC 4 AA/S 4.1.2 2CDG110202R0011 0.19 1
2-fold, SM – AA/A 2.1.2 2CDG110203R0011 0.30 1

AA/A 2.1.2
