ABB i-bus® KNX
Visualisation, Display and Signalling

Busch-ControlTouch® KNX Application
Busch-ControlTouch is a visualisation server for mobile end devices (iOS and Android) and
Window computers. Not only to visualise and control your complete KNX installation but also:
• Sonos Bridge with a complete integration of the Sonos API (Works with Sonos) (NEW)
• Can be used as a Bridge between KNX and Philips Hue
• Visualisation of your IP camera's, with support of pan, till and zoom
• Unlimited time programs and scenes and they can be edited by the end user
6136/APP-500 • Integrate Webpages into your design for maybe weather information or traffic information
• Alarm messages can be sent as email or as a push notification (including a snapshot of an
IP camera) but can also be heard on your Sonos System (NEW)
• Can be used as a UPnP bridge, so you can control e.g. your UPnP enabled Receiver via KNX
• Statistics and charts support with 5 period types (hour, day, week, month, year)
• Unrestricted personal profiles with an unlimited number of pages and controls
• Easy to use presence simulation, that can be edit by the end customer and with no limita-
tion of participants
• Visualisation functions: dimmer, RGB(W) control, switch, blind and shutter, heating/cool-
ing, air conditioning, scenes, button row (max. 6 buttons), IP camera, status display, value
transmitter, Sonos control, and UPnP control
• Has a flexible and unrestricted Script Editor for more complex logical functions based on
LUA (NEW)
• Automatic cloud backups including scenes, time programs and presence simulation data
(NEW)
• Complete commissioning is online and live. You can do it from everywhere and you don't
need to drive to the customer
• First commissioning with Wizard support (NEW)
• Loading the software into the device can be done without Internet
• Device has a direct KNX interface or can communicate via an IP Interface via the bus
• Visualisation as a list view and/or with background pictures with round, rectangle or trans-
parent controls (NEW)
• Secured remote access via our Cloud solution (For this function, you pay a monthly fee)
• Functional extensions and updates via firmware and software updates.
Security: 14
This device supports extensive security options to protect your installation and privacy.
All communication between the app your installation and our cloud is encrypted and always
based on the highest possible standards. The communication between the different parts al-
ways requires a username and password. The end user can also protect pages with a pin
code, Touch ID or Face ID. Additionally end users can set up local users with access rights to
shield certain parts of the home installation or allow them access only to specific parts.
External power supply: 5-36 V DC (SELV)
Control element: freely programmable touch surfaces
Bus voltage: 24 V
Protection class (Device): IP 20
Temperature range (Device): 0 °C to 70 °C
Dimensions: (L x W x D): 90 mm x 72 mm x 60 mm, Module width: 4 MW

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code € kg pc.
4 6136/APP-500 2CKA006136A0202 0.254 1
