ABB i-bus® KNX
User Operation – Design Ranges –
Functional Overview

Program ABB-tacteo

Vertical (86 mm x 157 mm) TB/U12.7.1-CG TBR/U4.7.1-CG TSN/U.2.1-CG TSM/U.2.1-CG
Horizontal (157 mm x 86 mm) TB/U12.8.1-CG TBR/U4.8.1-CG
Control element
Standard function ■ ■ ■ ■
Additional function ■ ■ – –
Indication
Display – ■ – –
Actual temperature display – ■ – –
Status display via text and/or ICON – ■ – –
RTC
Manual operation – ■ – –
Heating and/or cooling with/
without additional stage – ■ – –
Fan coil – ■ – –
Master/slave – ■ – –
Basic load – ■ – –
Internal and/or external
actual temperature sensor – ■ – –
Internal actual temperature sensor ■ ■ ■ ■
Installation
VDE ■ ■ ■ ■
BS ■ ■ ■ ■
IT (only as 157 mm x 86 mm) – – ■ ■
NEMA (only as 86 mm x 157 mm) ■ ■ ■ ■ 14

—
 = Function is supported
– = Function is not supported
