          ABB i-bus® KNX
          User Operation – Design Ranges –
          Multifunction Control Elements


                                  Control element, Multi-function/colour concept
                                  For BCU 6120/12-101-500 or 6120/13-500. With labelling field. Support of KNX functions
                                  through innovative colour concept or standard illumination red/green. Push switch function:
                                  switching/dimming/blind/sending values/scenes etc. Transparent labelling sheet with stan-
                                  dard symbols included in delivery. Incl. 10 logic channels (light scene actuator, sequence actua-
                                  tor, logic gates, etc.). Display elements: Two LED per rocker via separate communication object
                                  for status (Red/Green/OFF) or orientation light.











                                  6125/02                   6126/02                   6127/02


                                  Control element, 1/2-fold    Control element, 2/4-fold  Control element, 4/8-fold
                                  Multi-function/colour concept  Multi-function/colour concept  Multi-function/colour concept
                                  With 1 Control element: rocker switch left/right  With 2 Control elements: rocker switch left/right With 4 Control elements: rocker switch left/right
          Pack  Weight Description  Order details     Price   Order details     Price   Order details     Price
          unit  1 pc.                                 1 pc.                     1 pc.                     1 pc.
          pc.  kg
                                  Type      Order code      Type      Order code      Type      Order code
                  future® linear
          1       anthracite      6125/02-81-500  2CKA006115A0216  6126/02-81-500  2CKA006116A0206  6127/02-81-500  2CKA006117A0232
          1       savanne/ivory   6125/02-82-500  2CKA006115A0217  6126/02-82-500  2CKA006116A0207  6127/02-82-500  2CKA006117A0233
          1       aluminium silver  1)  6125/02-83-500  2CKA006115A0218  6126/02-83-500  2CKA006116A0208  6127/02-83-500  2CKA006117A0234
          1       davos/studio white  6125/02-84-500  2CKA006115A0219  6126/02-84-500  2CKA006116A0209  6127/02-84-500  2CKA006117A0235
          1       studio white, matt  1)  6125/02-884-500 2CKA006115A0226  6126/02-884-500 2CKA006116A0216  6127/02-884-500 2CKA006117A0242
          1       black, matt  1)  6125/02-885-500 2CKA006115A0227  6126/02-885-500 2CKA006116A0217  6127/02-885-500 2CKA006117A0243

                  solo®
          1       savanne/ivory   6125/02-82-500  2CKA006115A0217  6126/02-82-500  2CKA006116A0207  6127/02-82-500  2CKA006117A0233
  14
          1       davos/studio white  6125/02-84-500  2CKA006115A0219  6126/02-84-500  2CKA006116A0209  6127/02-84-500  2CKA006117A0235
          1       meteor/grey metallic  1)  6125/02-803-500 2CKA006115A0224  6126/02-803-500 2CKA006116A0214  6127/02-803-500 2CKA006117A0240

                  carat®
          1       anthracite      6125/02-81-500  2CKA006115A0216  6126/02-81-500  2CKA006116A0206  6127/02-81-500  2CKA006117A0232
          1       savanne/ivory   6125/02-82-500  2CKA006115A0217  6126/02-82-500  2CKA006116A0207  6127/02-82-500  2CKA006117A0233
          1       davos/studio white  6125/02-84-500  2CKA006115A0219  6126/02-84-500  2CKA006116A0209  6127/02-84-500  2CKA006116A0209

                  pure stainless steel  1)
          1       stainless steel  6125/02-866-500 2CKA006115A0223  6126/02-866-500 2CKA006116A0213  6127/02-866-500 2CKA006117A0239

                  Busch-axcent®
          1       davos/studio white  6125/02-84-500  2CKA006115A0219  6126/02-84-500  2CKA006116A0209  6127/02-84-500  2CKA006117A0235
                  Dynasty®
          1       anthracite      6125/02-81-500  2CKA006115A0216  6126/02-81-500  2CKA006116A0206  6127/02-81-500  2CKA006117A0232
          1       savanne/ivory   6125/02-82-500  2CKA006115A0217  6126/02-82-500  2CKA006116A0207  6127/02-82-500  2CKA006117A0233
          1       antique brass   6125/02-840-500 2CKA006115A0452  6126/02-840-500 2CKA006116A0227  6127/02-840-500 2CKA006117A0252
          1)  Surface painted
