14/302 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB i-bus® KNX
WaveLINE Wireless Control – Transmitter

WaveLINE-Switch Sensor 1-fold
1gang wall-mounted transmitter independent of mains power supply. For switching and
dimming. For controlling blinds and light scenes. 1 radio channel can be operated or up to
2 light scenes can be called up. For flush-mounted WaveLINE actuators 6701-101, 6702, 6703,
6704 and 6705-101. For LED display WaveLINE 6730-xxx. Compatible with WaveLINE KNX
6731-214-500
gateway TP-RF 6770. Send frequency: 868 MHz. Free-field range: approx. 100 m. Power sup-
ply: lithium button cell battery Type CR2032. Battery included in delivery; service life: typi-
cally 5 years.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
6731-84-500
Type code Order code kg pc.
white – 6731-212-500 2CKA006730A0028 0.076 1/10
alpine white – 6731-214-500 2CKA006730A0030 0.08 1/10
ivory white – 6731-82-500 2CKA006730A0032 0.076 1/10
aluminium silver – 6731-83-500 2CKA006730A0035 0.094 1/10
studio white – 6731-84-500 2CKA006730A0038 0.096 1/10
stainless steel – 6731-866-500 2CKA006730A0041 0.096 1/10
antique brass – 6731-840-500 2CKA006730A0094 0.086 1/10

WaveLINE-Switch Sensor 2-fold
2gang wall-mounted transmitter independent of mains power supply. With labelling field
and labelling strip. For switching and dimming. For controlling blinds and light scenes. 2 ra-
dio channels can be operated or up to 4 light scenes can be called up. For flush-mounted
WaveLINE actuators 6701-101, 6702, 6703, 6704 and 6705-101. For LED display WaveLINE
6732-214-500
6730-xxx. Compatible with WaveLINE KNX gateway TP-RF 6770. Send frequency: 868 MHz.
Free-field range: approx. 100 m. Power supply: lithium button cell battery Type CR2032.
Battery included in delivery; service life: typically 5 years.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
14
6732-84-500
Type code Order code kg pc.
white – 6732-212-500 2CKA006730A0029 0.078 1/10
alpine white – 6732-214-500 2CKA006730A0031 0.078 1/10
ivory white – 6732-82-500 2CKA006730A0033 0.078 1/10
aluminium silver – 6732-83-500 2CKA006730A0036 0.096 1/10
studio white – 6732-84-500 2CKA006730A0039 0.096 1/10
stainless steel – 6732-866-500 2CKA006730A0042 0.096 1/10
antique brass – 6732-840-500 2CKA006730A0095 0.086 1/10
