Door entry system
ABB-Welcome - Outdoor station modules

Keypad with 1abc input
Description Digital inputing module for
keypad outdoor station
Features - Enables the opening of the door using a numerical code
- 3,000 passwords can be taught in
- Customized passwords are allowed
- Backlight automatically on for visibility at night
- Call guard unit is available
Technical details - Dimensions: 97 x 72 x 25 mm
- Rating current: 24 V DC, 20 mA
- Operating temperature: -40 °C…+55 °C
Version Stainless steel White Aluminum
Article no. 51381K-S 51381K-W 51381K-A
Order no. 2TMA130160X0001 2TMA130010W0014 2TMA210160A0009

Display
Description Display module ensure the customized message, code, and legible number always can be
readed.
Features - Physical address / logical address calling type
- Opening of the door by DESFire or NFC or IC card.
- Wiegand output available
- Up to 5000 pcs cards can be registered
Technical details - Dimensions: 97 x 72 x 25 mm
- Rating current: 24 V DC, 160 mA
- Operating temperature: -40 °C…+55 °C
Version IC/DES fire card ID Card
Article no. 51382CR 51381CR
Order no. 2TMA130160N0009 2TMA130160N0010
