AL wall-mounting compact distribution boards
Accesories cabinet doors

PW GU Suitable for ... Type Order code

Sheet steel doors* 2
Single door
1 3 AL31 T100 2CPX062057R9999
4 AL41 T10 2CPX062059R9999
5 AL51 T11 2CPX062062R9999
6 AL61 T12 2CPX062066R9999
2 2 AL22 T220 2CPX062056R9999
3 AL32 T200 2CPX062058R9999
4 AL42 T20 2CPX062060R9999
5 AL52 T21 2CPX062063R9999
6 AL62 T22 2CPX062067R9999
7 AL72 T23 2CPX062070R9999
Right double door
T20 3 *1 4 AL43 T30R 2CPX062195R9999
5 AL53 T31R 2CPX062199R9999
6 AL63 T32R 2CPX062203R9999
7 AL73 T33R 2CPX062207R9999
4 *1 5 AL54 T31R 2CPX062199R9999
6 AL64 T32R 2CPX062203R9999
Left double door
3 *1 4 AL43 T30L 2CPX062196R9999
5 AL53 T31L 2CPX062200R9999
6 AL63 T32L 2CPX062204R9999
7 AL73 T33L 2CPX062208R9999
4* 1 5 AL54 T51L 2CPX062202R9999
6 AL64 T52L 2CPX062206R9999

Transparent doors* 2
1 3 AL31 TTS100 2CPX062021R9999
4 AL41 TTS10 2CPX062026R9999
5 AL51 TTS11 2CPX062031R9999
6 AL61 TTS12 2CPX062036R9999
2 3 AL32 TTS200 2CPX062022R9999
4 AL42 TTS20 2CPX062027R9999
5 AL52 TTS21 2CPX062032R9999
6 AL62 TTS22 2CPX062037R9999
7 AL72 TTS23 2CPX062042R9999
3* 1 4 AL43 TTS30 2CPX062028R9999
5 AL53 TTS31 2CPX062033R9999
6 AL63 TTS32 2CPX062038R9999
TTS20
7 AL73 TTS33 2CPX062043R9999
18
4* 1 5 AL54 TTS41 2CPX062034R9999
6 AL64 TTS42 2CPX062039R9999
* 1 3 or more panels wide: double-wing doors
* 2 Leave not less than 2 space units (SU) for DIN rail devices behind the closure
