TwinLine N 55 wall cabinets and floor-standing cabinets
General accessories

Unmounted Installed in the cabinet*
Article Unit Type Order code Type Order code
Cable clamp rails
For mounting in the cabinet
For TwinLine-L and TwinLine-W
Field width 1 = 250 mm 1 TZ311 2CPX010469R9999 TZ311A 2CPX010808R9999
TZ313 Field width 2 = 500 mm 1 TZ312 2CPX010470R9999 TZ312A 2CPX010809R9999
Field width 3 = 750 mm 1 TZ313 2CPX010471R9999 TZ313A 2CPX010810R9999
Field width 4 = 1000 mm 1 TZ314 2CPX010472R9999 TZ314A 2CPX010811R9999
Field width 5 = 1250 mm 1 TZ315 2CPX010785R9999 TZ315A 2CPX010812R9999
Field width 6 = 1500 mm 1 TZ316 2CPX010786R9999 TZ316A 2CPX010813R9999
Middle support rails
For mounting in the cabinet,
mounting brackets are included
in the scope of delivery
TZ433 2 mounting strips are additionally
needed (TZ601, TZ602 or TZ603,
depending on the cabinet depth).
Field width 1 = 250 mm 1 TZ431 2CPX010960R9999 TZ431A 2CPX010966R9999
Field width 2 = 500 mm 1 TZ432 2CPX010961R9999 TZ432A 2CPX010967R9999
Field width 3 = 750 mm 1 TZ433 2CPX010962R9999 TZ433A 2CPX010968R9999
Field width 4 = 1000 mm 1 TZ434 2CPX010963R9999 TZ434A 2CPX010969R9999
Field width 5 = 1250 mm 1 TZ435 2CPX010964R9999 TZ435A 2CPX010970R9999
Field width 6 = 1500 mm 1 TZ436 2CPX010965R9999 TZ436A 2CPX010971R9999
* Only in conjunction with the factory-installed meter and distributor fields, combination kits or CombiLine modules

Article Unit Type Order code
External mounting lugs* 4 ZW125P4 2CPX062461R9999
To mount the cabinet on the wall

ZW125P4

Transport eye bolts 4 TZ615P4 2CPX010510R9999

TZ615P4

IP55 protective frame for cabinet stacking
Required for insulated cabinets 1 TZ609 2CPX010504R9999
Required for earthed cabinets 1 TZ626 2CPX010778R9999
TZ609

IP55 Connection set for cabinet stacking 1 TZ608 2CPX010503R9999 18
For wall cabinets side by side or on top of each other order 1 x TZ608
For standing cabinets order 2 x TZ608
TZ608
Door hinge 180 degrees* 1 TZ607 2CPX010502R9999
Color RAL 9005

TZ607
Pin for door hinge 180 degrees* 10 TZ630P10 2CPX010929R9999
TZ630P10
* Included in the scope of delivery
