18/202 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Interior expansion system CombiLine N
Plastic partitions

Height
Article RE BH Unit Type Order code
Vertical partitions, plastic 3 00 1 ZX69 2CPX039069R9999
Not fault arc-proof, separation from adjacent module, 4 0 1 ZX70 2CPX039070R9999
distribution panel, meter panel, partition is inserted
in adjacent module in the cover bracket, color similar 5 1 1 ZX71 2CPX039071R9999
to RAL 7035 6 2 1 ZX72 2CPX039072R9999
7 3 1 ZX73 2CPX039073R9999
8 4 1 ZX74 2CPX039074R9999
9 5 1 ZX75 2CPX039075R9999

ZX69

Width
Article FB mm Unit Type Order code
Horizontal partitions, plastic 1 250 1 ZX86 2CPX039086R9999
Not fault arc-proof, separation from adjacent module, 2 500 1 ZX87 2CPX039087R9999
distribution panel, meter panel, partition is inserted
in adjacent module in the cover bracket, color similar
to RAL 7035

ZX86
