Interior expansion system CombiLine N
WR mounting frame parts

• Vertical WR profile rail
• For the height compensation when using transverse
profile rails
ZW213
Kit Mounted
Height not installed and installed in the cabinet
Description RE mm Unit Type Order code Type Order code
Vertical WR profile rail 1 150 1 ZW367 2CPX041850R9999 ZWM367 2CPX041432R9999
2 300 1 ZW368 2CPX041851R9999 ZWM368 2CPX041433R9999
3 450 1 ZW369 2CPX041852R9999 ZWM369 2CPX041434R9999
4 600 1 ZW370 2CPX041853R9999 ZWM370 2CPX041435R9999
5 750 1 ZW371 2CPX041854R9999 ZWM371 2CPX041436R9999
6 900 1 ZW372 2CPX041855R9999 ZWM372 2CPX041437R9999
7 1050 1 ZW373 2CPX041856R9999 ZWM373 2CPX041438R9999
8 1200 1 ZW374 2CPX041857R9999 ZWM374 2CPX041439R9999
9 1350 1 ZW375 2CPX041858R9999 ZWM375 2CPX041440R9999
10 1500 1 ZW376 2CPX041859R9999 ZWM376 2CPX041441R9999
11 1650 1 ZW377 2CPX041860R9999 ZWM377 2CPX041442R9999
12 1800 1 ZW213 2CPX060141R9999 ZWM213 2CPX041430R9999
10 ZW213P10 2CPX062641R9999 - -
300 ZW213P300 2CPX062714R9999 - -
13 1950 1 ZW378 2CPX041861R9999 ZWM378 2CPX041443R9999
14 2100 1 ZW214 2CPX060142R9999 ZWM214 2CPX041431R9999
10 ZW214P10 2CPX062642R9999 - -

• Horizontal transverse profile rails for field distribution
• Including fastening screws
• Two transverse profile rails are required for field
distribution upwards and downwards
ZW165
Kit Mounted
Width not installed and installed in the cabinet
Description FB mm Unit Type Order code Type Order code
Horizontal transverse profile rail 1 250 1 ZW164 2CPX042866R9999 ZWM164 2CPX042857R9999
10 ZW164P10 2CPX062710R9999 - -
2 500 1 ZW165 2CPX041862R9999 ZWM165 2CPX041444R9999
10 ZW165P10 2CPX062711R9999 - -
3 750 1 ZW166 2CPX041863R9999 ZWM166 2CPX041445R9999
10 ZW166P10 2CPX062712R9999 - -
4 1000 1 ZW167 2CPX041864R9999 ZWM167 2CPX041446R9999
10 ZW167P10 2CPX062713R9999 - -
5 1250 1 ZW168 2CPX042950R9999 - - 18
6 1500 1 ZW163 2CPX042951R9999 - -

• As transverse profile rails in the WR mounting frame

ZW209
Horizontal WR profile rail 1 186 1 ZW209 2CPX039207R9999 - -
2 436 1 ZW210 2CPX060138R9999 - -
3 686 1 ZW211 2CPX060139R9999 - -
4 936 1 ZW212 2CPX060140R9999 - -
