Interior expansion system parts
Busbar brackets and accessories

Article Use for... Unit Type Order code
Busbar bracket 5-pole M(B)H...50 1 ZB5 2CPX038459R9999
Busbar center distance 40 mm M(B)S...24 10 ZB5P10 2CPX062556R9999
For copper rails 12 x 5 mm, 12 x 10 mm
and 20 x 5 mm
ZB5
Busbar bracket 1-pole - 1 ZX147 2CPX044011R9999
Busbar center distance 60 mm 10 ZX147P10 2CPX062719R9999
For copper rails 12 x 5 mm to 30 x 10 mm
ZX147 For adding in a row on ZX146

Busbar bracket 3-pole M(B)R...02(B) 1 ZX146 2CPX044010R9999
Busbar center distance 60 mm M(B)R...H 10 ZX146P10 2CPX062718R9999
For copper rails 12 x 5 mm to 30 x 10 mm M(B)R...03

ZX146

End cover M(B)H...50 1 ZX172 2CPX060232R9999
For busbar carrier ZX146/ZB5 M(B)R...02(B) 10 ZX172P10 2CPX062724R9999
M(B)S...24
ZX172

N/PE busbar carrier - 1 ZX157 2CPX044009R9999
For copper rails 12 x 5 mm to 30 x 5 mm 10 ZX157P10 2CPX062722R9999
And 12 x 10 mm to 20 x 10 mm
ZX157 For adding in a row on ZX151

Busbar bracket 3-pole M(B)S...27 1 ZX151 2CPX044006R9999
Busbar center distance 60 mm 10 ZX151P10 2CPX062721R9999
For copper rails 12 x 5 mm to 30 x 10 mm
ZX151

End cover - 1 ZX158 2CPX060208R9999
For busbar carrier ZX151 10 ZX158P10 2CPX062723R9999

ZX158

Busbar bracket 3-pole
Busbar center distance 60 mm/100 mm M(B)L...52(B) 1 ZX520 2CPX067861R9999
For copper rails 30 x 10 mm to 60 x 10 mm M(B)S...31
10 ZX520P10 2CPX062552R9999
ZX520 Busbar center distance 100 mm/ 185 mm M(B)L...00(B) 1 ZX522 2CPX067909R9999
For copper rails 30 x 10 mm to 100 x 10 mm ML...B 10 ZX522P10 2CPX062553R9999

Busbar bracket 3-/4-pole M(B)L25 1 ZX523 2CPX068553R9999
Busbar center distance 185 mm M(B)L35
For copper rails 40 x 10 mm
ZX523
