18/230 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Interior expansion system parts
Covers, 1-field width with cutout/with viewing window

Article Use for... Unit Type Order code
Cover , 1-field width, with 90° press-and-turn lock
Height x width
150 x 250 mm, with cutout M(B)U156 1 AG132 2CPX062992R9999
For measuring devices, 96 x 96 mm
AG132

300 x 250 mm, with cutout M(B)U157 1 AG164 2CPX062890R9999
For measuring devices, 96 x 96 mm

AG164

450 x 250 mm, with cutout M(B)U158 1 AG165 2CPX062891R9999
For measuring devices, 96 x 96 mm

AG165

450 x 250 mm, with cutout MD152B 1 AG240 2CPX042127R9999
For 3 x NH-fuse switch disconnector NH00
100 mm busbar center distance

AG240
750 x 250 mm, with cutout MD100B 1 AG243 2CPX042187R9999
For 4 x NH-fuse switch disconnector NH00
185 mm busbar center distance

AG243
900 x 250 mm, with cutout MBD100E 1 AG246 2CPX042190R9999
For 4 x NH-fuse switch disconnector NH00 +
EFM
185 mm busbar center distance

AG246

Covers with viewing window
1-field width, with 90° press-and-turn lock
300 x 250 mm, with viewing window - 1 AG12S 2CPX062228R9999
18
450 x 250 mm, with viewing window - 1 AG13S 2CPX062230R9999
600 x 250 mm, with viewing window - 1 AG14S 2CPX062232R9999
AG12S
