Interior expansion system parts
Cover parts

Article Use for... Unit Type Order code
Cover bracket 45 mm tall M(B)R...03 4 ED137P4 2CPX062600R9999
For fastening (inserting, turning) on EDF 40 ED137P40 2CPX062601R9999
profile rails as well as latching a bulkhead;
For DIN rails 35 x 7.5 mm,
only use this cover bracket
ED137P4

Cover bracket 52.5 mm tall All modules 4 ED138P4 2CPX062630R9999
For fastening (inserting, turning) on EDF 12 ED138P12 2CPX062602R9999
and WR profile rails, as well as for latching
a partition wall, for DIN rails, 35 x 15 mm, 40 ED138P40 2CPX062603R9999
only use this cover bracket 1600 ED138P1600 2CPX062702R9999
ED138P4

Cover bracket 88 mm tall 4 ED139P4 2CPX062604R9999
For fastening (inserting, turning) on EDF 40 ED139P40 2CPX062734R9999
and WR profile rails, as well as for latching
a partition wall; to be used when installing
devices at greater depths or with busbar
systems
ED139P4

Spacer piece M(B)R...03 4 ED135P4 2CPX062610R9999
To extend the cover holder by 25 mm 40 ED135P40 2CPX062733R9999

ED135P4
Cover bracket 1 ED110 2CPX039320R9999
1 set left / right

ED110

DIN rails adapter 10 ED58P10 2CPX062338R9999
For cover brackets ED138 and ED139 to be
snapped onto the DIN rail from the front
ED58P10

90 degree press-and-turn lock All covers 12 ED50P12 2CPX062337R9999
ED50P12

Screw insert 4 ED136P4 2CPX062611R9999
Fr metric thread, M5, for mounting macrolon,
sheet metal or aluminum plates on the
EDF cover brackets
ED136P4
18
90 degree press-and-turn lock 4 ED41P4 2CPX062332R9999
For mounting macrolon, sheet metal or
aluminum plates on the cover brackets
ED41P4

Sealing nipple 5 ZB35P5 2CPX062392R9999
for subsequent installation in standard
field covers (6 mm hole must be drilled)
ZB35P5
