Internal expansion system - Combination sets
Mounting plates, terminal blocks and Tmax circuit

250 mm 500 mm
• Mounting plates that are variably adjustable in depth via the
deep angle piece ED33
300 mm • Combination sets are plugged into the distribution panel at
the top or bottom and mounted on the other side of the
cabinet
• The maximum installation depth between mounting plate
ED61MA ED62MA and cover is 178 mm

Height Width
RE mm FB mm PLE From cabinet depth Type Order code
2 300 1 250 24 200 ED61MA 2CPX037820R9999
2 500 48 200 ED62MA 2CPX037821R9999

250 mm 500 mm • With horizontally-arranged DIN rails 35 x 15 mm
• DIN rails can be set up to be protection-insulated with the
insulator piece ZK90P2 if necessary
300 mm • Row spacing 150 mm (can be moved when it is needed)
• Combination sets are plugged into the distribution panels
at the top and bottom and attached on the other side of
the cabinet
ED61KA ED62KA

2 300 1 250 24 200 ED61KA 2CPX037822R9999
2 500 48 200 ED62KA 2CPX037823R9999
3 450 1 250 36 200 ED91KA 2CPX037824R9999
2 500 72 200 ED92KA 2CPX037825R9999

• For power switches ABB T-max
• ED250T3, Tmax XT1, 2 x 3-pole, 1 x 4-pole
Tmax XT3, 1 x 3-pole, 1 x 4-pole, in the small distributor only
1 x Tmax XT1 with rocker arm max. I to 100 A
n
• ED320T4, Tmax, T4, 3-pole
ED250T3 ED320T4 ED630T5 • ED630T5, Tmax, T4, 4-pole and Tmax, T5, 3- and 4-pole
Combination sets can only be used in combination with
distribution panels
2 300 1 250 24 200 ED250T3 2CPX037826R9999
3 450 1 250 36 200 ED320T4 2CPX037827R9999
2 500 72 200 ED630T5 2CPX037828R9999 18
