Automation boards
Ordering codes - SRX enclosures

Slotted internal plate
Fixing with small parts supplied. Depth-adjustable using a special spacer kit (to be ordered
separately).

Piastra interna asolata
Dimensions (mm) Package/
No. of
H W Code pieces
300 200 TQ3020 1/1
300 400 TQ3040 1/1
400 300 TQ4030 1/1
400 400 TQ4040 1/1
400 600 TQ4060 1/1
500 400 TQ5040 1/1
600 400 TQ6040 1/1
600 600 TQ6060 1/1
700 500 TQ7050 1/1
800 600 TQ8060 1/1
800 800 TQ8080 1/1
1000 800 TQ1080 1/1
1200 600 TQ1260 1/1
1200 800 TQ1280 1/1

Clip nuts
For slotted plates with M6x10mm hexagonal head screws.

Package/
No. of
Description Code pieces
Clip nuts TQ6610 1/20

Spacer kit for adjusting back plate depth
Kit made up of 12 spacers for fixing the mounting plate. Allows depth adjustment in 25 mm
steps.

Package/
No. of
Description Code pieces
Spacers, length 25 mm AA8025 1/12
25 mm

Spacers, length 50 mm AA8050 1/12
50 mm
