Page 13 - SACE Tmax XT - Technical Catalogue
P. 13
INSTALL ATION 1/9
01
Power In XT7- XT7 M
[W/pole] [A]
F w
Ekip Dip 800 24 35
Ekip Touch
1000 37 55
1250 57 86
1600 94 141
Power losses gives indication of the heat generated under specified conditions. Measurement of power
losses are perfomed on new samples in free air (according to Annex G of IEC).
The measurement of resistance cannot be directly related to the power loss of the device and is not
enough to ascertain the quality of the contacts.
