MILD STEEL ENCLOSURES

MILD STEEL ENCLOSURES IP66 GREY - SINGLE DOOR
Features:
No of
- RAL 7035 Grey, UV tolerant hardened polyester Dimensions (mm) Mounting Cable No of Hinges Weight Part No.
Entry
H x W x D
Plate
Locks
Grey
(kg)
powder coat.
- Injected ployurethane sealing gasket. 200 x 200 x 150 170 x 150 80 x 150 1 2 2.5 MSB202015G
300 x 200 x 150 270 x 150 80 x 150 1 2 3.9 MSB302015G
300 x 250 x 150 270 x 200 80 x 150 1 2 4.6 MSB302515G
300 x 300 x 150 270 x 250 80 x 200 1 2 5.4 MSB303015G
300 x 300 x 200 270 x 250 140 x 230 1 2 6.1 MSB303020G
300 x 400 x 150 270 x 350 80 x 300 1 2 6.5 MSB304015G
300 x 400 x 200 270 x 350 140 x 300 1 2 7.4 MSB304020G
400 x 300 x 150 370 x 250 80 x 200 1 2 6.8 MSB403015G
400 x 300 x 200 370 x 250 140 x 230 1 2 7.4 MSB403020G
400 x 400 x 150 370 x 350 80 x 300 1 2 8.2 MSB404015G
400 x 400 x 200 370 x 350 140 x 300 1 2 9.6 MSB404020G
400 x 600 x 200 370 x 550 140 x 500 1 2 12.9 MSB406020G
400 x 600 x 300 370 x 550 140 x 500 1 2 15.4 MSB406030G
500 x 400 x 150 470 x 350 80 x 300 2 2 10.8 MSB504015G
500 x 400 x 200 470 x 350 140 x 300 2 2 11.4 MSB504020G
MSB202015G
500 x 400 x 250 470 x 350 140 x 300 2 2 12.5 MSB504025G
500 x 500 x 200 470 x 450 140 x 300 2 2 13.6 MSB505020G
500 x 700 x 200 470 x 650 140 x 500 2 2 21.5 MSB507020G
METAL
500 x 700 x 250 470 x 650 140 x 500 2 2 22.1 MSB507025G ENCLOSURES
600 x 400 x 200 570 x 350 140 x 300 2 2 13.7 MSB604020G
600 x 400 x 250 570 x 350 140 x 300 2 2 14.3 MSB604025G
600 x 400 x 300 570 x 350 140 x 300 2 2 15.4 MSB604030G
600 x 500 x 200 570 x 450 140 x 400 2 2 16.0 MSB605020G
600 x 600 x 200 570 x 550 140 x 500 2 2 21.4 MSB606020G
600 x 600 x 300 570 x 550 140 x 500 2 2 25.2 MSB606030G
600 x 600 x 400 570 x 550 140 x 500 2 2 30.1 MSB606040G
700 x 500 x 200 670 x 450 140 x 400 2 2 21.5 MSB705020G
700 x 500 x 250 670 x 450 140 x 400 2 2 22.4 MSB705025G
700 x 600 x 200 670 x 550 140 x 400 2 2 23.5 MSB706020G
800 x 600 x 200 770 x 550 140 x 500 2 3 27.9 MSB806020G
800 x 600 x 250 770 x 550 140 x 500 2 3 30.2 MSB806025G
800 x 600 x 300 770 x 550 140 x 500 2 3 32.8 MSB806030G
800 x 600 x 400 770 x 550 140 x 500 2 3 34.0 MSB806040G
800 x 800 x 200 770 x 750 140 x 700 2 3 37.2 MSB808020G
800 x 800 x 300 770 x 750 140 x 700 2 3 39.7 MSB808030G
800 x 800 x 400 770 x 750 140 x 700 2 3 43.1 MSB808040G
1000 x 600 x 200 970 x 550 140 x 500 3 Point 3 42.5 MSB106020G
1000 x 600 x 300 970 x 550 140 x 500 3 Point 3 44.8 MSB106030G
MSB504015G
1000 x 800 x 200 970 x 750 140 x 700 3 Point 3 47.0 MSB108020G
1000 x 800 x 250 970 x 750 140 x 700 3 Point 3 49.0 MSB108025G
1000 x 800 x 300 970 x 750 140 x 700 3 Point 3 51.4 MSB108030G
1000 x 1000 x 300 970 x 950 140 x 900 3 Point 3 61.4 MSB101030G
1000 x 1000 x 400 970 x 950 140 x 900 3 Point 3 63.2 MSB101040G
1200 x 600 x 200 1170 x 550 140 x 500 3 Point 3 46.6 MSB126020G
1200 x 600 x 300 1170 x 550 140 x 500 3 Point 3 48.6 MSB126030G
1200 x 600 x 400 1170 x 550 140 x 500 3 Point 3 54.0 MSB126040G
1200 x 800 x 250 1170 x 750 140 x 700 3 Point 3 57.0 MSB128025G
1200 x 800 x 300 1170 x 750 140 x 700 3 Point 3 58.6 MSB128030G
1200 x 1000 x 300 1170 x 950 140 x 900 3 Point 3 76.0 MSB121030G
1200 x 1000 x 400 1170 x 950 140 x 900 3 Point 3 78.7 MSB121040G

MILD STEEL ENCLOSURES IP55 GREY - DOUBLE DOOR
Dimensions (mm) Mounting Cable No of No of Weight Part No.
H x W x D Plate Entry Locks Hinges (kg) Grey
800 x 1000 x 300 770 x 950 140 x 900 3 Point 3 48.1 MSB801030DDG
800 x 1200 x 300 770 x 1150 2 x (140 x 500) 3 Point 3 58.0 MSB801230DDG
1000 x 1000 x 300 970 x 950 140 x 900 3 Point 3 59.9 MSB101030DDG
1000 x 1200 x 300 970 x 1150 2 x (140 x 500) 3 Point 3 78.0 MSB101230DDG
1200 x 1200 x 300 1170 x 1150 2 x (140 x 500) 3 Point 3 91.0 MSB121230DDG
MSB801030DDG 1400 x 1000 x 300 1370 x 950 2 x (140 x 500) 3 Point 3 80.6 MSB141030DDG
1400 x 1200 x 300 1370 x 1150 2 x (140 x 500) 3 Point 3 94.0 MSB141230DDG

Phone: 1300 556 601 www.ipd.com.au V16-IA-ME-R02 593
