MILD STEEL ENCLOSURE ACCESSORIES

CANOPIES - GREY
Features: Part No.
- RAL 7035 Grey UV tolerant hardened polyester Description Grey
powdercoat. Roof Canopy Grey RAL7035 for 200W x 150D TEJ2015G
- Slopes front to back.
Roof Canopy Grey RAL7035 for 250W x 150D TEJ2515G
Roof Canopy Grey RAL7035 for 300W x 150D TEJ3015G
Roof Canopy Grey RAL7035 for 300W x 200D TEJ3020G
Roof Canopy Grey RAL7035 for 400W x 150D TEJ4015G
Roof Canopy Grey RAL7035 for 400W x 200D TEJ4020G
Roof Canopy Grey RAL7035 for 400W x 250D TEJ4025G
Roof Canopy Grey RAL7035 for 400W x 300D TEJ4030G
Roof Canopy Grey RAL7035 for 500W x 200D TEJ5020G
Roof Canopy Grey RAL7035 for 500W x 250D TEJ5025G
TEJ2015G Roof Canopy Grey RAL7035 for 600W x 200D TEJ6020G
Roof Canopy Grey RAL7035 for 600W x 250D TEJ6025G
Roof Canopy Grey RAL7035 for 600W x 300D TEJ6030G
Roof Canopy Grey RAL7035 for 600W x 400D TEJ6040G
Roof Canopy Grey RAL7035 for 800W x 200D TEJ8020G
Roof Canopy Grey RAL7035 for 800W x 250D TEJ8025G
Roof Canopy Grey RAL7035 for 800W x 300D TEJ8030G
METAL
Roof Canopy Grey RAL7035 for 1000W x 300D TEJ1030G ENCLOSURES
Roof Canopy Grey RAL7035 for 1000W x 400D TEJ1040G
Roof Canopy Grey RAL7035 for 1200W x 300D TEJ1230G

CANOPIES - ORANGE
Features: Part No.
- RAL 2008 Orange Epoxy powder coat. Description Orange
- Slopes front to back.
Roof Canopy Orange RAL2008 for 200W x 150D TEJ2015A
Roof Canopy Orange RAL2008 for 400W x 200D TEJ4020A
Roof Canopy Orange RAL2008 for 500W x 200D TEJ5020A
Roof Canopy Orange RAL2008 for 600W x 200D TEJ6020A
Roof Canopy Orange RAL2008 for 600W x 300D TEJ6030A
Roof Canopy Orange RAL2008 for 800W x 200D TEJ8020A
Roof Canopy Orange RAL2008 for 800W x 250D TEJ8025A
Roof Canopy Orange RAL2008 for 800W x 300D TEJ8030A
Roof Canopy Orange RAL2008 for 1000W x 300D TEJ1030A
TEJ2015A Roof Canopy Orange RAL2008 for 1200W x 300D TEJ1230A

ENCLOSURE PLINTHS
Features:
- RAL 7035 Grey UV tolerant Polyester powdercoat. Description Part No.
Steel Plinth 100H for 600W x 250D Grey RAL7035 ZCLA106025
Steel Plinth 100H for 600W x 300D Grey RAL7035 ZCLA106030
Steel Plinth 100H for 800W x 200D Grey RAL7035 ZCLA108020
Steel Plinth 100H for 800W x 250D Grey RAL7035 ZCLA108025
Steel Plinth 100H for 800W x 300D Grey RAL7035 ZCLA108030
Steel Plinth 100H for 1000W x 300D Grey RAL7035 ZCLA101030
ZCLA106025 Steel Plinth 100H for 1000W x 400D Grey RAL7035 ZCLA101040
Steel Plinth 100H for 1200W x 300D Grey RAL7035 ZCLA101230

Features: DIN RAIL INSERTS
- Galvanised DIN chasis.
- Includes slotted escutcheon in RAL 7035 Grey. Enclosure Size Modules No of Rows Part No.
- All fixing hardware included. 400H x 400W x 150-200D 45 3 x 15 CH4040-1520
400H x 600W x 150-200D 78 3 x 26 CH4060-1520
400H x 600W x 250-300D 78 3 x 26 CH4060-2530
600H x 400W x 150-200D 64 4 x 16 CH6040-1520
600H x 400W x 250-300D 64 4 x 16 CH6040-2530
600H x 600W x 150-200D 104 4 x 26 CH6060-1520
600H x 600W x 250-300D 104 4 x 26 CH6060-2530
1000H x 600W x 200D 156 6 x 26 CH1060-20
1000H x 600W x 300D 156 6 x 26 CH1060-30
CH4040-1520
