Page 67 - sasil-plus-catalogue-2009

SASILplus / SASILplus

Gerätezubehör / Device accessories
Wechselskalen für Dreheisenmessgeräte; 48mm x 48mm
Dial gauges for moving iron measuring devices; 48mm x 48mm
SASIL-Kabelan- Wandlerübersetzung Skala
schlussseite Artikel-Nr. Seite
SASIL-side of cable com- Transformer ratio Scale Typ / Type Article-No. Page
[A]
[A]
partment
0-60/120 WS-D-AU/1/60-120 A8025141 A-115
0-75/150 WS-D-AU/1/75-150 A8025142 A-115
0-100/200 WS-D-AU/1/100-200 A8025143 A-115
0-125/250 WS-D-AU/1/125-250 A8025144 A-115
0-150/300 WS-D-AU/1/150-300 A8025145 A-115
Anschluss unten (AU) N/1 0-200/400 WS-D-AU/1/200-400 A8025146 A-115
Connection bottom (AU)
0-250/500 WS-D-AU/1/250-500 A8025147 A-115
0-300/600 WS-D-AU/1/300-600 A8025148 A-115
0-400/800 WS-D-AU/1/400-800 A8025149 A-115
0-500/1000 WS-D-AU/1/500-1000 A8025150 A-115
0-600/1200 WS-D-AU/1/600-1200 A8025151 A-115
0-60/120 WS-D-AU/5/60-120 A8026141 A-115
0-75/150 WS-D-AU/5/75-150 A8026142 A-115
0-100/200 WS-D-AU/5/100-200 A8026143 A-115
0-125/250 WS-D-AU/5/125-250 A8026144 A-115
0-150/300 WS-D-AU/5/150-300 A8026145 A-115
Anschluss unten (AU)
Connection bottom (AU) N/5 0-200/400 WS-D-AU/5/200-400 A8026146 A-115
0-250/500 WS-D-AU/5/250-500 A8026147 A-115
0-300/600 WS-D-AU/5/300-600 A8026148 A-115
0-400/800 WS-D-AU/5/400-800 A8026149 A-115
0-500/1000 WS-D-AU/5/500-1000 A8026150 A-115
0-600/1200 WS-D-AU/5/600-1200 A8026151 A-115

Wechselskalen für Bimetallmessgeräte;48mm x 48mm; 8min. Einstellzeit
Dial gauges for bimetal measuring devices; 48mm x 48mm; setting time 8min.
0-100/120 WS-MB8-AU/1/100-120 A8027120 A-115
0-125/150 WS-MB8-AU/1/125-150 A8027121 A-115
0-150/180 WS-MB8-AU/1/150-180 A8027122 A-115
0-200/240 WS-MB8-AU/1/200-240 A8027123 A-115
Anschluss unten (AU)
Connection bottom (AU) N/1 0-250/300 WS-MB8-AU/1/250-300 A8027124 A-115
0-300/360 WS-MB8-AU/1/300-360 A8027125 A-115
0-400/480 WS-MB8-AU/1/400-480 A8027126 A-115
0-500/600 WS-MB8-AU/1/500-600 A8027127 A-115
0-600/720 WS-MB8-AU/1/600-720 A8027128 A-115

A-64
