SASILplus / SASILplus

Gerätezubehör / Device accessories
Analogmessgeräte; 48mm x 48mm; steckbar / Analogue measuring devices; 48mm x 48mm; pluggable
Bimetallmessgeräte mit Skalen; Einstellzeit 15min. / Bimetal measuring devices with scales; setting time 15min.
SASIL-Kabelan- Wandlerübersetzung Skala
schlussseite VE Größe Artikel-Nr. Seite
SASIL-side of cable Transformer ratio PU Size Scale Typ / Type Article-No. Page
[A]
[A]
compartment
00 100-120 MB15-AR-SASIL-P00/100-120/5 A8548120 A-114f
00 125-150 MB15-AR-SASIL-P00/125-150/5 A8548121 A-114f
00 150-180 MB15-AR-SASIL-P00/150-180/5 A8548122 A-114f
1-3 100-120 MB15-AR-SASIL-P1-3/100-120/5 A8448120 A-114f
1-3 125-150 MB15-AR-SASIL-P1-3/125-150/5 A8448121 A-114f
Anschluss rechts (AR) 1-3 150-180 MB15-AR-SASIL-P1-3/150-180/5 A8448122 A-114f
Connection right (AR) N/5A 1 1-3 200-240 MB15-AR-SASIL-P1-3/200-240/5 A8448123 A-114f

1-3 250-300 MB15-AR-SASIL-P1-3/250-300/5 A8448124 A-114f
SASILplus
1-3 300-360 MB15-AR-SASIL-P1-3/300-360/5 A8448125 A-114f SASILplus
1-3 400-480 MB15-AR-SASIL-P1-3/400-480/5 A8448126 A-114f
1-3 500-600 MB15-AR-SASIL-P1-3/500-600/5 A8448127 A-114f
1-3 600-720 MB15-AR-SASIL-P1-3/600-720/5 A8448128 A-114f
00 100-120 MB15-AL-SASIL-P00/100-120/5 A8548140 A-114f SASIT / SALIT
SASIT / SALIT
00 125-150 MB15-AL-SASIL-P00/125-150/5 A8548141 A-114f
00 150-180 MB15-AL-SASIL-P00/150-180/5 A8548142 A-114f
1-3 100-120 MB15-AL-SASIL-P1-3/100-120/5 A8448140 A-114f
1-3 125-150 MB15-AL-SASIL-P1-3/125-150/5 A8448141 A-114f
Anhang
Anschluss links (AL) N/5A 1 1-3 150-180 MB15-AL-SASIL-P1-3/150-180/5 A8448142 A-114f Appendix
Connection left (AL) 1-3 200-240 MB15-AL-SASIL-P1-3/200-240/5 A8448143 A-114f
1-3 250-300 MB15-AL-SASIL-P1-3/250-300/5 A8448144 A-114f
1-3 300-360 MB15-AL-SASIL-P1-3/300-360/5 A8448145 A-114f
1-3 400-480 MB15-AL-SASIL-P1-3/400-480/5 A8448146 A-114f
1-3 500-600 MB15-AL-SASIL-P1-3/500-600/5 A8448147 A-114f
1-3 600-720 MB15-AL-SASIL-P1-3/600-720/5 A8448148 A-114f
