SASILplus / SASILplus

Gerätezubehör / Device accessories
Analogmessgeräte; 48mm x 48mm; steckbar / Analogue measuring devices; 48mm x 48mm; pluggable
Bimetallmessgeräte mit Skalen; Einstellzeit 8min. / Bimetal measuring devices with scales; setting time 8min.
SASIL-Kabelan- Wandlerübersetzung Skala
schlussseite VE Größe Artikel-Nr. Seite
SASIL-side of cable Transformer ratio PU Size Scale Typ / Type Article-No. Page
[A]
[A]
compartment
00 100-120 MB8-AR-SASIL-P00/100-120/1 A8545120 A-114f
00 125-150 MB8-AR-SASIL-P00/125-150/1 A8545121 A-114f
00 150-180 MB8-AR-SASIL-P00/150-180/1 A8545122 A-114f
1-3 100-120 MB8-AR-SASIL-P1-3/100-120/1 A8445120 A-114f
1-3 125-150 MB8-AR-SASIL-P1-3/125-150/1 A8445121 A-114f
Anschluss rechts (AR) 1-3 150-180 MB8-AR-SASIL-P1-3/150-180/1 A8445122 A-114f
Connection right (AR) N/1A 1 1-3 200-240 MB8-AR-SASIL-P1-3/200-240/1 A8445123 A-114f

1-3 250-300 MB8-AR-SASIL-P1-3/250-300/1 A8445124 A-114f
1-3 300-360 MB8-AR-SASIL-P1-3/300-360/1 A8445125 A-114f
1-3 400-480 MB8-AR-SASIL-P1-3/400-480/1 A8445126 A-114f
1-3 500-600 MB8-AR-SASIL-P1-3/500-600/1 A8445127 A-114f
1-3 600-720 MB8-AR-SASIL-P1-3/600-720/1 A8445128 A-114f
00 100-120 MB8-AL-SASIL-P00/100-120/1 A8545140 A-114f
00 125-150 MB8-AL-SASIL-P00/125-150/1 A8545141 A-114f
00 150-180 MB8-AL-SASIL-P00/150-180/1 A8545142 A-114f
1-3 100-120 MB8-AL-SASIL-P1-3/100-120/1 A8445140 A-114f
1-3 125-150 MB8-AL-SASIL-P1-3/125-150/1 A8445141 A-114f
Anschluss links (AL) N/1A 1 1-3 150-180 MB8-AL-SASIL-P1-3/150-180/1 A8445142 A-114f
Connection left (AL) 1-3 200-240 MB8-AL-SASIL-P1-3/200-240/1 A8445143 A-114f
1-3 250-300 MB8-AL-SASIL-P1-3/250-300/1 A8445144 A-114f
1-3 300-360 MB8-AL-SASIL-P1-3/300-360/1 A8445145 A-114f
1-3 400-480 MB8-AL-SASIL-P1-3/400-480/1 A8445146 A-114f
1-3 500-600 MB8-AL-SASIL-P1-3/500-600/1 A8445147 A-114f
1-3 600-720 MB8-AL-SASIL-P1-3/600-720/1 A8445148 A-114f
