SASILplus / SASILplus

Gerätezubehör / Device accessories
Analogmessgeräte; 48mm x 48mm; steckbar / Analogue measuring devices; 48mm x 48mm; pluggable
Bimetallmessgeräte mit Skalen; Einstellzeit 15min. / Bimetal measuring devices with scales; setting time 15min.
SASIL-Kabelan- Wandlerübersetzung Skala
schlussseite VE Größe Artikel-Nr. Seite
SASIL-side of cable Transformer ratio PU Size Scale Typ / Type Article-No. Page
[A]
[A]
compartment
00 100-120 MB15-AR-SASIL-P00/100-120/1 A8547120 A-114f
00 125-150 MB15-AR-SASIL-P00/125-150/1 A8547121 A-114f
00 150-180 MB15-AR-SASIL-P00/150-180/1 A8547122 A-114f
1-3 100-120 MB15-AR-SASIL-P1-3/100-120/1 A8447120 A-114f
1-3 125-150 MB15-AR-SASIL-P1-3/125-150/1 A8447121 A-114f
Anschluss rechts (AR) 1-3 150-180 MB15-AR-SASIL-P1-3/150-180/1 A8447122 A-114f
Connection right (AR) N/1A 1 1-3 200-240 MB15-AR-SASIL-P1-3/200-240/1 A8447123 A-114f

1-3 250-300 MB15-AR-SASIL-P1-3/250-300/1 A8447124 A-114f
1-3 300-360 MB15-AR-SASIL-P1-3/300-360/1 A8447125 A-114f
1-3 400-480 MB15-AR-SASIL-P1-3/400-480/1 A8447126 A-114f
1-3 500-600 MB15-AR-SASIL-P1-3/500-600/1 A8447127 A-114f
1-3 600-720 MB15-AR-SASIL-P1-3/600-720/1 A8447128 A-114f
00 100-120 MB15-AL-SASIL-P00/100-120/1 A8547140 A-114f
00 125-150 MB15-AL-SASIL-P00/125-150/1 A8547141 A-114f
00 150-180 MB15-AL-SASIL-P00/150-180/1 A8547142 A-114f
1-3 100-120 MB15-AL-SASIL-P1-3/100-120/1 A8447140 A-114f
1-3 125-150 MB15-AL-SASIL-P1-3/125-150/1 A8447141 A-114f
Anschluss links (AL) N/1A 1 1-3 150-180 MB15-AL-SASIL-P1-3/150-180/1 A8447142 A-114f
Connection left (AL) 1-3 200-240 MB15-AL-SASIL-P1-3/200-240/1 A8447143 A-114f
1-3 250-300 MB15-AL-SASIL-P1-3/250-300/1 A8447144 A-114f
1-3 300-360 MB15-AL-SASIL-P1-3/300-360/1 A8447145 A-114f
1-3 400-480 MB15-AL-SASIL-P1-3/400-480/1 A8447146 A-114f
1-3 500-600 MB15-AL-SASIL-P1-3/500-600/1 A8447147 A-114f
1-3 600-720 MB15-AL-SASIL-P1-3/600-720/1 A8447148 A-114f
