SASILplus / SASILplus

Gerätezubehör / Device accessories
Analogmessgeräte; 48mm x 48mm; steckbar / Analogue measuring devices; 48mm x 48mm; pluggable
Bimetallmessgeräte mit Skalen; Einstellzeit 8min. / Bimetal measuring devices with scales; setting time 8min.
SASIL-Kabelan- Wandlerübersetzung Skala
schlussseite VE Größe Artikel-Nr. Seite
SASIL-side of cable Transformer ratio PU Size Scale Typ / Type Article-No. Page
[A]
[A]
compartment
00 100-120 MB8-AR-SASIL-P00/100-120/5 A8546120 A-114f
00 125-150 MB8-AR-SASIL-P00/125-150/5 A8546121 A-114f
00 150-180 MB8-AR-SASIL-P00/150-180/5 A8546122 A-114f
1-3 100-120 MB8-AR-SASIL-P1-3/100-120/5 A8446120 A-114f
1-3 125-150 MB8-AR-SASIL-P1-3/125-150/5 A8446121 A-114f
Anschluss rechts (AR) 1-3 150-180 MB8-AR-SASIL-P1-3/150-180/5 A8446122 A-114f
Connection right (AR) N/5A 1 1-3 200-240 MB8-AR-SASIL-P1-3/200-240/5 A8446123 A-114f

1-3 250-300 MB8-AR-SASIL-P1-3/250-300/5 A8446124 A-114f
SASILplus
1-3 300-360 MB8-AR-SASIL-P1-3/300-360/5 A8446125 A-114f SASILplus
1-3 400-480 MB8-AR-SASIL-P1-3/400-480/5 A8446126 A-114f
1-3 500-600 MB8-AR-SASIL-P1-3/500-600/5 A8446127 A-114f
1-3 600-720 MB8-AR-SASIL-P1-3/600-720/5 A8446128 A-114f
00 100-120 MB8-AL-SASIL-P00/100-120/5 A8546140 A-114f SASIT / SALIT
SASIT / SALIT
00 125-150 MB8-AL-SASIL-P00/125-150/5 A8546141 A-114f
00 150-180 MB8-AL-SASIL-P00/150-180/5 A8546142 A-114f
1-3 100-120 MB8-AL-SASIL-P1-3/100-120/5 A8446140 A-114f
1-3 125-150 MB8-AL-SASIL-P1-3/125-150/5 A8446141 A-114f
Anhang
Anschluss links (AL) N/5A 1 1-3 150-180 MB8-AL-SASIL-P1-3/150-180/5 A8446142 A-114f Appendix
Connection left (AL) 1-3 200-240 MB8-AL-SASIL-P1-3/200-240/5 A8446143 A-114f
1-3 250-300 MB8-AL-SASIL-P1-3/250-300/5 A8446144 A-114f
1-3 300-360 MB8-AL-SASIL-P1-3/300-360/5 A8446145 A-114f
1-3 400-480 MB8-AL-SASIL-P1-3/400-480/5 A8446146 A-114f
1-3 500-600 MB8-AL-SASIL-P1-3/500-600/5 A8446147 A-114f
1-3 600-720 MB8-AL-SASIL-P1-3/600-720/5 A8446148 A-114f
