P. 16
FEATURES: HELIO FUSE NH1PV - UP TO 1000V DC
• I.R. DC (UL), 50kA
(L/R=1ms) Rated DIN Pack Part No.
Current (A) Size Quantity
• Breaking capacity 25kA
• Standard size 1 fuse 50 3 NH1PV-050
• Standard IEC 60269-6
63 3 NH1PV-063
80 3 NH1PV-080
1
100 3 NH1PV-100
125 3 NH1PV-125
160 3 NH1PV-160
200 3 NH2PV-200
2
250 3 NH2PV-250
NH1PV-050
FEATURES: FUSE BASE FOR NH1PV FUSE - UP TO 1000VDC
• Touch protection
Rated DIN Suitable Fuse
• DIN or screw mounting Part No.
Current (A) Size Size
• Shrouded to IP20
250 1 NH1 K-NH1GSHB
• Single pole design
400 2 NH2 K-NH2GSHB
K-NH1GSHB
16 | Solar DC Products
