carat®
Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Control element Comfort timer control element )
For Busch-Blind control II insert 6411 U-101, For manual and time-controlled switching of blinds,
6411 U/S-101. roller blinds, awnings, lighting and other electrical
For basic blind insert 6418 U. devices.
For Busch-Universal 2gang 1way insert 6402 U. With dusk to dawn program including (Astro-program)
Individual Astro adjustment and Astro blocking time.
The controlled devices can be manually operated at any
anthracite 6430-81-102 2CKA006430A0326 1/10 time.
ivory white 6430-82-102 2CKA006430A0327 1/10 Simple setting via high-resolution display with
background illumination.
studio white 6430-84-102-500 2CKA006430A0400 1/10
With preset switching times/date/time.
Factory-set switching times can be individually
Cover plate ) 1 adjusted.
with rotary knob Automatic switchover from summer time to winter time
For comfort blinds insert 6419 U. (switch-off function).
Switching times/programme are safely stored in the
event of a mains power failure.
Power reserve for time and date > 10 years.
Simple toggling between manual/automatic/vacation
anthracite 6436-81 2CKA006430A0387 10 modes.
ivory white 6436-82 2CKA006430A0356 10 Combined with Busch-Blind control II insert
6411 U/S-101, sun protection and twilight function.
studio white 6436-84 2CKA006430A0358 10
Freely adjustable temperature and brightness-
1) Continuous lighting of the turn knob possible using glow lamp 3855. Not included dependent sun protection function.
in delivery. Neutral wire required for operation with neon lamp. Freely adjustable twilight function.
User-adjustable running times for blinds and air
conditioning. 11
Standard timer control element )
1
For manual and time-controlled switching of blinds and Programming possible only with control element
roller blinds. attached and energized.
With dusk to dawn program including (Astro-program) 6 switching times per day can be user-defined for each
Individual Astro adjustment and Astro blocking time. day of the week.
The controlled devices can be manually operated at any Astro switching times and switching times can be
time. combined.
Simple setting via high-resolution display with When combined with LED dimmer 6524 U, Busch-
background illumination. Universal master dimmer insert 6593 U or Busch-
With preset switching times/date/time. Memory touch-type controller 6550 U-101, the
Factory-set switching times can be individually brightness of the lighting can be adjusted for each ON
adjusted. switching time.
Automatic switchover from summer time to winter time For Busch-Blind control II insert 6411 U-101,
(switch-off function). 6411 U/S-101.
Switching times/programme are safely stored in the For Busch-Universal relay switch insert 6401 U-102.
event of a mains power failure. For Busch-Universal master dimmer insert 6593 U.
Power reserve for time and date > 10 years. For LED dimmer insert 6524 U and 6526 U..
Simple toggling between manual/automatic/vacation For Busch-Memory touch-type controller 6550 U-101.
modes. Temperature range (Device): 0 °C to 35 °C
Programming possible only with control element 6455-101-500 2CKA006410A0399 1/10
attached and energized. 1) See respective cover plates 6435-xx.
2 switching times per day can be user-defined for each
day of the week.
2
1
Astro switching times and switching times can be Time switch mechanism 16 A ) )
combined. DP, break contact for staircases, exterior lighting, fans,
For basic blind insert 6418 U. etc.
Temperature range (Device): 0 °C to 35 °C Running time: 15 min
For time-programmed switching of electrical
6456-101 2CKA006410A0398 1/10
consumers.
1) See respective cover plates 6435-xx. Rated voltage: 230 V~, +10 % / -10 %
Rated current: 16 A, cos φ 0.25
Protection class (Device): IP 20
1070 U 2CKA001043A0025 1/10
1) For screw-fixing only
2) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
