carat®
Socket outlets Data communication
Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty
SCHUKO® socket outlet ) ) ) WLAN access point, flush-mounted ) )
1
2
2
1
3
with hinged lid and labelling field power supply from mains power
Shuttered. Operation as WLAN access point for the connection of
With screwless terminals. WLAN terminal devices to the LAN.
DP (2 P + E) Operation as WLAN repeater for extending the
with hinged lid transmission range of a WLAN.
Size of labelling field: 60 x 9 mm. Operation as WLAN adapter for integrating Ethernet
Rated voltage: 250 V~ terminal devices into a WLAN.
Rated current: 16 A Supports WLAN standards IEEE 802.11b/g/n with
Protection class (Device): IP 20 2.4 GHz; integrated WLAN antenna.
Backward connection of an Ethernet cable via screw
anthracite 20 EUKNB-81 2CKA002018A1537 10/100
terminals (10/100 Mbit/s).
ivory white 20 EUKNB-82 2CKA002018A1538 10/100 Front-side Ethernet connection via a RJ45 socket
studio white 20 EUKNB-84 2CKA002018A1540 10/100 (10/100 Mbit/s).
The three connections (WLAN, Ethernet/screw terminals
1) Increased shock protection .
2) The labels are clamped under the labelling field. and Ethernet/RJ45)can be used in parallel via the
3) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com. integrated switch.
Power supply via 2-pole connecting terminal.
Nominal voltage: 100 - 240 V~
SCHUKO® socket outlet ) For mounting in commercially available deep flush-
1
with hinged lid and lock mounted and hollow-wall boxes.
Shuttered. Rated frequency: 50 Hz - 60 Hz
With screwless terminals. Protection class (Device): IP 20
DP (2 P + E) 8186/31-101-500 2CKA008100A0359 1
With different lock mechanism.
Delivery includes 2 keys. 1) Suitable for cover plate 1803-xxx.
Rated voltage: 250 V~ 2) Not to be mounted in SM box 1701-xxx, 1702-xxx, 1703-xxx.
11
Rated current: 16 A
Protection class (Device): IP 20 Reset magnet
anthracite 20 EUKNBSL-81 2CKA002018A1557 10 For resetting WLAN access point UP 8186/31-101 and
WLAN access point PoE UP 8186/41 to the factory
ivory white 20 EUKNBSL-82 2CKA002018A1559 10
settings.
studio white 20 EUKNBSL-84 2CKA002018A1563 10 Protection class (Device): IP 20
1) Increased shock protection .
8186/11-500 2CKA008100A0361 1
1
SCHUKO® socket outlet )
with hinged lid and lock 1
Shuttered. Universal data connection unit, cat. 3 )
With screwless terminals. 1gang
DP (2 P + E) With down-leading outlet.
With evenly engaging lock. For 8-pole plug, RJ 11/12, RJ 45, ISDN capability, Cat. 3.
Delivery includes 2 keys. Design according to IEC 60 603-7-2:2007.
Rated voltage: 250 V~ Screw contacts
Rated current: 16 A With claw.
Protection class (Device): IP 20 Protection class (Device): IP 20
0213-500 2CKA000230A1549 10/100
anthracite 20 EUKNBSL-81-101 2CKA002018A1558 10
1) Suitable for cover plate 1803-xxx.
ivory white 20 EUKNBSL-82-101 2CKA002018A1560 10
studio white 20 EUKNBSL-84-101 2CKA002018A1564 10
Universal data connection box with down-leading
1) Increased shock protection .
outlet )
1
2gang internally parallel connected
SCHUKO® socket outlet ) ) ) With down-leading outlet.
3
1
2
with hinged lid, labelling field and LED control light For 8-pole plug, RJ 11/12, RJ 45, ISDN capability, Cat. 3.
Shuttered. Design according to IEC 60 603-7-2:2007.
With screwless terminals. Screw contacts
DP (2 P + E) With claw.
with hinged lid Protection class (Device): IP 20
Size of labelling field: 60 x 9 mm. 0214 2CKA000230A0235 10/100
Rated voltage: 250 V~
Rated current: 16 A Mounting 35 mm deep flush 1gang
Protection class (Device): IP 20 boxes: or Dual Box 3070-2/35 BSDB.
anthracite 20 EUKNBL-81 2CKA002018A1548 10/100 2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
ivory white 20 EUKNBL-82 2CKA002018A1549 10/100
neon indicator: not applicable
studio white 20 EUKNBL-84 2CKA002018A1551 10/100
1) Suitable for cover plate 1803-02-xxx.
1) Increased shock protection .
