          carat®
          Multimedia / communication adapters




          Product    Article-No.    Order-No.       Pack/Qty  Product     Article-No.    Order-No.       Pack/Qty


                     Cover plate                                          Cover plate for Busch-powerDock
                     For loudspeaker insert 8223 U.                       For Busch-powerDock charging cradle.




          anthracite  8253-81       2CKA008200A0078  1/10     anthracite  6477-81        2CKA006400A0056  10
          ivory white  8253-82      2CKA008200A0079  1/10     ivory white  6477-82       2CKA006400A0057  10
          studio white  8253-84     2CKA008200A0081  1/10     studio white  6477-84      2CKA006400A0059  10/100

                     Cover plate                                          Cover plate
                     For telephone connection unit.                       For USB charging station 6474 U.
                     For USB, VGA, HDMI inserts and communication         With protective function against lateral slipping of the
                     adapter.                                             mobile telephone.
                     USB power adapter insert 6472 U.                     Suitable for devices with a maximum thickness of 18
                     For loudspeaker connection box.                      mm.
                     Suitable for part number 0248/0x-101.                With frontal mounting option of connecting cable.
                     For data modules.                        anthracite  6478-81-500    2CKA006400A0013  1
                     Suitable for Art. No. 0219/12 and 0219/13.
                     For modular outlets with 90° RJ45 outlet from   ivory white  6478-82-500  2CKA006400A0015  1
                     Telegärtner (type MJ and WE).            studio white  6478-84-500  2CKA006400A0019  1
                     Protection class (Device): IP 20
          anthracite  1766-81       2CKA001710A3613  10
          ivory white  1766-82      2CKA001710A3144  10/100                                                            11
          studio white  1766-84-500  2CKA001710A3992  10/100

                     Cover plate
                     with metal mounting plate
                     With fixing claws.
                     loudspeaker inserts and cover.
                     Conductor cross-sections up to 4 mm² rigid.
                     With screw-type terminals.
                     Protection class (Device): IP 20
          anthracite  1751-81       2CKA001723A0253  10
          ivory white  1751-82      2CKA001723A0239  10
          studio white  1751-84     2CKA001723A0240  10/100

                     Cover plate
                     with rotary control, with marking
                     As a cover for volume controllers.
                     Suitable for the "LR 15 mono BJ UP" devices of WHD.
                     Protection class (Device): IP 20

          anthracite  1740 DR/03-81  2CKA001710A4120  10
          ivory white  1740 DR/03-82  2CKA001710A3807  10
          studio white  1740 DR/03-84  2CKA001710A3808  10


                     Cover plate
                     For Busch Bluetooth receiver 8219 U.




          anthracite  8255-81       2CKA008200A0211  1
          ivory white  8255-82      2CKA008200A0212  1
          studio white  8255-84     2CKA008200A0214  1/10
