solo®
Movement detectors / comfort switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Universal 2gang 1way insert Busch-Watchdog MOS-Fet Insert ) ) ) ) ) )
2
1
3
6
5
4
3 wire connection (neutral conductor required). 2-wire connection (neutral conductor not required)
For the serial switch operating mode: 2 separate For Busch-Watchdog 180 flush-mounted Sensor
outputs, 2 separate extension inputs. Standard 6810-21x-101.
For operation mode timer: output 1 (eg lighting), output For Busch-Watchdog 180 flush-mounted sensor
2: ON/Off delay in dependence of output 1 (eg fan Comfort II 6800-xxx-104 and 6800-xxx-104M.
control). For Busch-Watchdog Presence tech 6813-xxx-101 und
For Busch-Watchdog 180 flush-mounted Sensor 6813/11-xxx.
Standard 6810-21x-101. Combinable with Busch-Watchdog extension insert
For Busch-Watchdog 180 flush-mounted sensor 6805 U.
Comfort II 6800-xxx-104 and 6800-xxx-104M. Operation also possible via conventional push buttons
For Busch-Watchdog Presence tech 6813-xxx-101 und (2020 US, 2021/6 UK).
6813/11-xxx. Rated voltage: 230 V~, +10 % / -10 %
For Busch-Remote control IR control cover 6066-xxx-10x Rated frequency: 50 Hz
and 6067-xxx-10x. Suitable for: 230 V incandescent lamps, 230 V halogen
For control cover 6430-xxx-10x and 6543-xxx-10x. lamps and low-voltage halogen lamps with conventional
Combinable with Busch-Watchdog extension insert transformers or Busch Electronic Transformer.
6805 U. Rated power: 60 - 420 W/VA
Operation also possible via conventional push buttons
(2020 US, 2021/6 UK). Temperature range (Device): 0 °C to 35 °CBritish
Rated voltage: 230 V~, +10 % / -10 % Standard EN 60669-2-1
Rated frequency: 50 Hz
Outputs: 2x Normally open contact, potential-bound
Suitable for: 230 V incandescent lamps, 230 V halogen 6804 U-101-500 2CKA006800A2219 1/10
lamps, fluorescent lamps and low-voltage halogen 1) In case of electronic transformers, 5 % transformer losses.
lamps, that are operated via transformers. 2) In the case of conventional transformers, take ~20% transformer loss into account.
Rated current: 10 AX 3) Not suitable for the activation of energy-saving lamps, conventional and electronic 11
Rated power: 2300 W/VA ballast units and LED lamps.
4) Not suitable for activating the staircase time delay.
5) Cannot be used to control relais.
Temperature range (Device): 0 °C to 35 °CBritish 6) Requires an NIS international socket, E-No. 372507676.
Standard EN 60669-2-1

Busch-Watchdog extension insert ) 1
6402 U-500 2CKA006401A0051 1/10 3 wire connection (neutral conductor required).
Mounting 35 mm deep flush 1gang For extending Busch-Watchdog 180 flush-mounted and
boxes: or Dual Box 3070-2/35 BSDB. Busch-Watchdog Presence tech installations.
For combination with relay insert 6401 U-102 and
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only. 6402 U.
For combination with MOS-Fet insert 6804 U-101.
neon indicator: neon lamp 3855, one neon lamp is supplied together with For combination with Dimmer insert 6593 U and
control cover plates 6540-2x. 6550 U-101.
For Busch-Watchdog 180 flush-mounted sensor
Comfort II 6800-xxx-104 and 6800-xxx-104M.
Busch-Watchdog relay mechanism For Busch-Watchdog Presence tech 6813-xxx-101 und
3 wire connection (neutral conductor required). 6813/11-xxx.
For Busch-Watchdog 180 flush-mounted Sensor Rated voltage: 230 V~, +10 % / -10 %
Standard 6810-21x-101. Rated frequency: 50 Hz
For Busch-Watchdog 180 flush-mounted sensor Control/Signal outputs: 1, electronic output, potential-
Comfort II 6800-xxx-104 and 6800-xxx-104M. bound
For Busch-Watchdog Presence tech 6813-xxx-101 und Temperature range (Device): 0 °C to 35 °C
6813/11-xxx.
Rated voltage: 230 V, +10 % / -10 % 6805 U-500 2CKA006800A2161 1/10
Rated frequency: 50 Hz Mounting 35 mm deep flush 1gang
Outputs: 1x Normally open contact, potential-bound boxes: or Dual Box 3070-2/35 BSDB.
Suitable for: 230 V incandescent lamps, 230 V halogen
lamps, fluorescent lamps and low-voltage halogen Cover frames: 1gang frame 1721 BS-2xG
lamps, that are operated via transformers. or Dual Box frame 1722 BSDB-2xG.
Rated power: 700 W/VA 2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
Temperature range (Device): 0 °C to 55 °CBritish 1) Not combinable with relay switch insert 6812 U-101.
Standard EN 60669-2-1

6812 U-101-500 2CKA006800A2160 1/10
