11/334 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Sky Niessen
Signaling and lighting systems Blank covers / Cable outlets

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Cover for signaling light “Elevator” symbol Blank cover plate
Cover for signaling light with white diffuser and Included: mounting grid and cover plate.
“Elevator” symbol for LED lights code: 8180.1, 8180.2 & Without fixing claws.
8181.5.

8581.19 2CLA858110A1901 5 Soft White 8500 BL 2CLA850000A1101 10
Silver 8500 PL 2CLA850000A1301 10
Cover for signaling light “Exit” symbol Soft Black 8500 NS 2CLA850000A1501 10
Cover for signaling light with white diffuser and “Exit”
symbol for LED lights code: 8180.1, 8180.2 & 8181.5. Stainless Steel 8500 AI 2CLA850000A1401 10
Antique Gold 8500 OE 2CLA850000A1201 10

Cable outlet
8581.20 2CLA858120A1001 5 3 connection screw terminals up to 2,5 mm . 2
Cable tie included.
Included: fixing claws.
Cover for signaling light “Info point” symbol
Cover for signaling light with white diffuser and “Info Cover plate code: 8507.
point” symbol for LED lights code: 8180.1, 8180.2 & 8181.5.
8107 2CLA810700A1001 10

Cover plate for cable outlet
8581.21 2CLA858120A1101 5 Cover plate for cable outlet code: 8107.

Buzzer / Door bell
11
Product Article-No. Order-No. Pack/Qty
Soft White 8507 BL 2CLA850700A1101 10
Buzzer Silver 8507 PL 2CLA850700A1301 10
Rated voltage: 127 - 230 Vac / 50 - 60 Hz. Soft Black 8507 NS 2CLA850700A1501 10
Rated power: 8 VA.
Adjustable tone. Stainless Steel 8507 AI 2CLA850700A1401 10
Acoustic power at 1 meter with cover plate: 75 dB. Antique Gold 8507 OE 2CLA850700A1201 10
Without fixing claws.
Cover plate code: 8529.
8119 2CLA811900A1001 10

Electronic door bell with 4 melodies
Rated voltage: 230 Vac / 50-60 Hz.
4 melodies available.
Acoustic power at 1 meter with cover plate: 72 dB.
Without fixing claws.
Cover plate code: 8529.
8124.2 2CLA812420A1001 1

Cover plate for buzzer/door bell
Cover plate for buzzer / door bell code: 8119 & 8124.2.

Soft White 8529 BL 2CLA852900A1101 5
Silver 8529 PL 2CLA852900A1301 5
Soft Black 8529 NS 2CLA852900A1501 5
Stainless Steel 8529 AI 2CLA852900A1401 5
Antique Gold 8529 OE 2CLA852900A1201 5
