11/332 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Sky Niessen

Light controls - Rotatory switch Temperature controls - RTC

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

4 position rotatory switch Digital room thermostat
Rated voltage: 110 - 250 Vac. Rated voltage: 230 Vac - 50/60 Hz.
Rated current: 16 AX. Power consumption: < 1W
4 postions. Operating temperature range: + 0 ºC to 50 ºC.
4 circuits. Measurement accuracy: ±2 ºC (± 1 ºC with calibration).
Faston terminals. Resolution: 0.1 ºC.
Without fixing claws. Control output: Potential-free relay contacts Normally.
Cover plate code: 8554. Open (NO).
Maximum load: 3A cos = 0,5.
8154 2CLA815400A1001 10 Output relay operation modes:
- Hysteresis: 0.5 ºC.
- Pulse-width modulation: with a ±4 ºC difference with
Cover plate with knob for rotatory switch the set-point temperature, variable from 100% to 0%
Cover plate for rotatory switch code: 8154. modulation.
Mounting grid delivered with the cover plate
(without fixing claws).
Cover plate code: 8540.5.
Soft White 8554 BL 2CLA855400A1101 1 8140.5 2CLA814050A1001 1
Silver 8554 PL 2CLA855400A1301 1
Cover plate for digital thermostat
Soft Black 8554 NS 2CLA855400A1501 1
Cover plate for room thermostat code: 8140.5.
Stainless Steel 8554 AI 2CLA855400A1401 1
Antique Gold 8554 OE 2CLA855400A1201 1

Soft White 8540.5 BL 2CLA854050A1101 5
11
Silver 8540.5 PL 2CLA854050A1301 5
Soft Black 8540.5 NS 2CLA854050A1501 5
Stainless Steel 8540.5 AI 2CLA854050A1401 1
Antique Gold 8540.5 OE 2CLA854050A1201 1

Rotatory room thermostat with floor sensor
Rated voltage: 230 Vac ; ±10 % - 50/60 Hz.
Load power: 2.300 W.
Load type: floor heating resistor.
Control temperature: +5 ºC to +45 ºC (Set point).
OFF state: At OFF position, the thermostat is off, so that it
does not address the temperature measured by the floor
temperature probe. The relay output contact is open.
Temperature accuracy: 0,5 ºC.
Hysteresis: 0,5 ºC.
Floor temperature sensor: NTC, 10KΩ at 25ºC, -40ºC to
80ºC. Double isolated cable, 4m length.
LED light indication: Red and green.
Ambient temperature: -20 ºC to 45 ºC.
Without fixing claws.
Cover plate code: 8540.9.

8140.9 2CLA814090A1001 1
Cover plate with rotatory knob for RTC
Cover plate for room thermostat code: 8140.9.

Soft White 8540.9 BL 2CLA854090A1101 5
Silver 8540.9 PL 2CLA854090A1301 5
Soft Black 8540.9 NS 2CLA854090A1501 5
Stainless Steel 8540.9 AI 2CLA854090A1401 5
Antique Gold 8540.9 OE 2CLA854090A1201 5
