Sky Niessen
Light controls - Wireless control

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Wireless switch transmitter - 1 channel Wireless dimming actuator
1-gang wall-mounted transmitter independent of mains Rated voltage: 230 Vac ; ± 10% - 50/60 Hz
power supply. For wireless switching and dimming of electrical loads.
1 radio channel for switching, dimming, controlling blinds For functions ON/OFF switch and dimming.
or 2 light scenes can be called up. For wall mounted transmitter code: 8531.1 & 8531.2.
Repeater function can be activated for extended range.
For wireless actuators: 8130.4, 8130.5, 8130.7 & 8130.6. For universal attachment or installation.
Send frequency: 868 MHz. 2-wire connection (neutral conductor not required)
Free-field range: approx. 100 m. 3-wire connection system (neutral conductor is required)
Power supply: lithium button cell battery type CR2032. is preferred when using electronic transformers,
Battery service life: typically 5 years, therefore practically electromagnetic transformers and energy saving lamps.
maintenance-free. With auxiliary input for push-buttons code: 8104.X.
Rated voltage: 3 Vdc. Send/receive frequency: 868 MHz.
Automatic monitoring of battery life. Free-field range: approx. 100 m.
Control element: adjustable potentiometer
Including fixing plate for mounting on smooth walls or on Display elements: status indication of output via LED.
switch boxes. Outputs: 1 dimming channel, 230Vac
Control element: switch contacts top/bottom. Rated power:
Display elements: LED to indicate the transmission. - Incandescent lamps: 35 - 300 W
Temperature range device: -5 °C to 45 °C. - Low voltage halogen lamps, which are operated by
Battery included in delivery. electronic transformers: 35 - 200 VA
- Low voltage halogen lamps with conventional
transformers: 35 - 175 VA
Soft White 8531.1 BL 2CLA853110A1101 1 Temperature range device: -5 °C to 45 °C
Silver 8531.1 PL 2CLA853110A1301 1 Dimensions: (L x W x D): 47 mm x 48 mm x 33 mm
Soft Black 8531.1 NS 2CLA853110A1501 1
8130.5 2CLA813050A1001 1
Wireless switch transmitter - 2 channel
2-gang wall-mounted transmitter independent of mains Wireless blind actuator
power supply. Rated voltage: 230 Vac ; ±10 % - 50/60 Hz.
For wireless switching of electrical loads or controlling
2 radio channel for switching, dimming, controlling blinds blinds/shutters.
or 4 light scenes can be called up. 2 functions: 2-gang switch or blind control. 11
For wireless actuators: 8130.4, 8130.5, 8130.7 & 8130.6. Operation also possible via conventional blind controls
Send frequency: 868 MHz. code 8144.X or push-buttons 8104.X.
Free-field range: approx. 100 m. For wall mounted transmitter code: 8531.1 & 8531.2.
Power supply: lithium button cell battery type CR2032. With blind switch function: 3 minutes run time.
Battery service life: typically 5 years, therefore practically Repeater function can be activated for extended range.
maintenance-free. For universal attachment or installation.
Rated voltage: 3 Vdc. 3 wire connection (neutral conductor required).
Send/receive frequency: 868 MHz.
Automatic monitoring of battery life. Free-field range: approx. 100 m.
Including fixing plate for mounting on smooth walls or on Control element: adjustable potentiometer.
switch boxes. Display elements: status indication of output via LED.
Control element: switch contacts top/bottom. Inputs: 2.
Display elements: LED to indicate the transmission. Polling voltage: 230 V~, Sensing pulse, L-wire.
Temperature range device: -5 °C to 45 °C. Outputs: 2 Normally Open contact, 230 Vac.
Battery included in delivery. Rated power:
- Blind motors: 3 A, cos ϕ0.5.
- Incandescent/halogen lamps: 3 A.
Soft White 8531.2 BL 2CLA853120A1101 1 - Fluorescent lamps: 3 AX.
Silver 8531.2 PL 2CLA853120A1301 1 Temperature range device: -5 °C to 45 °C.
Dimensions: (L x W x D): 47 mm. x 48 mm. x 22 mm.
Soft Black 8531.2 NS 2CLA853120A1501 1
8130.7 2CLA813070A1001 1
Wireless switch actuator
Rated voltage: 230 Vac ; ± 10% - 50/60 Hz. Wireless DIN-rail actuator
For wireless switching of electrical loads. Rated voltage: 230 Vac ; ±10 % - 50/60 Hz.
2 functions: ON/OFF switch or time delayed switch. For wireless switching of electrical loads.
For wall mounted transmitter code: 8531.1 &8531.2. 2 functions: ON/OFF switch or time delayed switch.
Switch-off delay: 3 sec. / 1 min. / 5 min. / 15 min. For wall mounted transmitter code: 8531.1 &8531.2.
Switch-off delay:
Repeater function can be activated for extended range. 3 sec. / 1 min. / 5 min. / 10 min. / 30 min.
For universal attachment or installation. Repeater function can be activated for extended range.
3 wire connection (neutral conductor required). For DIN-rail installation.
With auxiliary input for push-buttons code: 8104.X. 3 wire connection (neutral conductor required).
Send/receive frequency: 868 MHz. Send/receive frequency: 868 MHz.
Free-field range: approx. 100 m. Free-field range: approx. 30 m.
Control element: adjustable potentiometer. Control element: adjustable potentiometer.
Display elements: status indication of output via LED. Display elements: status indication of output via LED.
Outputs: 1x Normally Open or Normally Closed contact,
Outputs: 1x Normally Open or Normally Closed contact, 230 Vac.
230 Vac. Rated power:
Rated power: - Incandescent, halogen, electronic transformer and
- Incandescent, halogen, electronic transformer and ferromagnetic transformers: 2.300 W / VA.
ferromagnetic transformers: 2.300 W / VA. - Fluorescent load: 1.000 VA.
- Fluorescent load: 1.000 VA. Temperature range device: -5 °C to 45 °C.
Temperature range (device): -5 °C to 45 °C. Dimensions: 1 module.
Dimensions: (L x W x D): 47 mm. x 48 mm. x 22 mm.
8130.6 2CLA813060A1001 1
8130.4 2CLA813040A1001 1
