11/330 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Sky Niessen
Light controls - Motion sensors Light controls - Programmable switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

MOS-Fet switch for motion sensor Relay switch
Rated voltage: 230 V~ ; ± 10% - 50/60 Hz. Rated voltage: 230 V~ ; ± 10% - 50/60 Hz.
2-wire connection (neutral conductor not required). 3 wire connection (neutral conductor required).
For timer control element 8165.31. Operation also
For 8541.1 motion sensor. possible via conventional push buttons 8104.X.
Operation also possible via conventional push buttons Outputs: 1 Normally open contact, potential-bound.
8104.X. Suitable for: 230 V incandescent lamps, 230 V halogen
lamps, fluorescent lamps and low-voltage halogen lamps,
Rated power: 60 - 420 W / VA. that are operated via transformers.
Suitable for: 230 V incandescent lamps, 230 V halogen Rated current: 10 AX.
lamps, low-voltage halogen lamps with conventional Rated power: 2300 W / VA.
transformers. Temperature range device: -25 °C to 55 °C.
Included: fixing claws.
Temperature range device: 0 °C to 35 °C.
In case of electronic transformers, 5 % transformer 8161 2CLA816100A1001 1
losses.
In the case of conventional transformers, take ~20%
transformer loss into account. Relay switch for blinds
Not suitable for the activation of energy-saving lamps, Rated voltage: 230 V~ ; ± 10% - 50 Hz.
conventional and electronic ballast units and LED lamps. Suitable for blind, roller blind and awning drives with
mechanical or electronic limit switch shut-off.
Not suitable for activating the staircase time delay. Two 230 V multi-way input terminals (Up/Down) for
Cannot be used to control relais. group control.
Included: fixing claws. Operating mode switch for the following modes: normal,
louvre, base station, position.
Wind alarm, cleaning functions can be accommodated via
extension input.
8141.3 2CLA814130A1001 1 For comfort timer control element 8565.31.
Remote control with blind controls code: 8144.X.
Running time: 3 min.
Relay switch for motion sensor Outputs: 2 Normally open contact.
Rated voltage: 230 V ; ± 10% - 50 Hz. Rated current: 3 A, cos ϕ0.5.
Rated power: 690 VA.
3 wire connection (neutral conductor required). Control/Signal outputs: 2.
11
For 8141.1 motion sensor. Temperature range device: 0 °C to 35 °C.
Outputs: 1 Normally open contact, potential-bound. Included: fixing claws.
Suitable for: 230 V incandescent lamps, 230 V halogen
lamps, fluorescent lamps and low-voltage halogen lamps, 8161.2 2CLA816120A1001 1
that are operated via transformers.
Rated power: 700 W / VA. Timer control element
Temperature range device: 0 °C to 55 °C. For manual and time-controlled switching of blinds, roller
Included: fixing claws. blinds, awnings, lighting and other electrical devices.
With dusk to dawn program including (Astro-program).
8141.4 2CLA814140A1001 1 Individual Astro adjustment and Astro blocking time.
The controlled devices can be manually operated at any time.
Simple setting via high-resolution display with back-
ground illumination.
180° motion sensor With preset switching times/date/time.
For automatic switching of devices dependent on motion Factory-set switching times can be individually adjusted.
and brightness. Automatic switchover from summer time to winter time
(switch-off function).
For relay inserts 8141.4. Switching times/programme are safely stored in the
For MOS-Fet insert 8141.3. event of a mains power failure. Power reserve for time
With integrated selector switch for ON-AUTOMATIC-OFF and date > 10 years. Simple toggling between manual/
automatic/vacation modes.
(lockable). Freely adjustable temperature and brightness-dependent sun
Surveillance density: 18 sectors with 72 switching protection function. Freely adjustable twilight function.
segments. User-adjustable running times for blinds and air conditioning.
Switch-off delay: 10 sec to 30 min or short-time pulse 1 Programming possible only with control element at-
tached and energized. 6 switching times per day can be
sec adjustable. user-defined for each day of the week. Astro switching
Temperature range device: 0 °C to 35 °C. times and switching times can be combined.
Detection range: frontal: 12 m, lateral: 8 m. For blind control insert 8161.2.
For universal relay switch insert 8161.
Brightness limit value: from 5 lux up to daytime Temperature range device: 0 °C to 35 °C.
operation. Cover plate code: 8565.3.
Detection angle: 180 °.
Mounting height: 0.8 m - 1.2 m. 8165.31 2CLA816530A1101 1
Soft White 8541.1 BL 2CLA854110A1101 1
Cover plate for timer control element
Silver 8541.1 PL 2CLA854110A1301 1 Cover plate for timer control element code: 8165.31.
Soft Black 8541.1 NS 2CLA854110A1501 1
Stainless Steel 8541.1 AI 2CLA854110A1401 1
Antique Gold 8541.1 OE 2CLA854110A1201 1
Soft White 8565.3 BL 2CLA856530A1101 1
Silver 8565.3 PL 2CLA856530A1301 1
Soft Black 8565.3 NS 2CLA856530A1501 1
Stainless Steel 8565.3 AI 2CLA856530A1401 1
Antique Gold 8565.3 OE 2CLA856530A1201 1
