Light controls - Timer switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Universal single relay time delayed switch Electronic rocker for time delayed switch
Rated voltage: 230 V~ ; ± 10% - 50 Hz. Electronic rocker for time delayed switch code:
For switching incandescent lamps, 230 V tungsten 8130.1 & 8130.2.
halogen lamps, fluorescent lamps and low-voltage
halogen lamps, that are actuated via transformers.
3 wire connection (neutral conductor required).
With operating mode switch for operating mode: switch, Soft White 8530 BL 2CLA853000A1101 1
time switch.
Switch operating mode: press on the upper rocker switch Silver 8530 PL 2CLA853000A1301 1
half to switch the light on, press on the lower rocker Soft Black 8530 NS 2CLA853000A1501 1
switch half to switch the light off.
Time switch operating mode: press on the upper rocker Stainless Steel 8530 AI 2CLA853000A1401 1
switch half to switch the light on, the light automatically Antique Gold 8530 OE 2CLA853000A1201 1
switches off after a time delay. Manual switching off not
possible. The delay can be set in 5 steps between 30 and
300 secs. Time delayed switch with triac
Operation also possible via conventional push buttons Rated voltage: 230 Vac - 50 Hz.
8104.X. Power:
Inputs: 1. - Incandescent: 40 - 500 W.
Polling voltage: 230 V~, Sensing pulse, L-wire. - Halogen with transformer: 40 - 400 VA.
Outputs: 1 Normally open contact, potential-bound. - Motors: 40 - 100 VA.
Suitable for: ohmic, capacitive and inductive loads. 2 wire connection.
Rated current: 10 AX. Delay setup: 10 sec. to 10 min.
Rated power: 2300 W / VA. Overcurrent protection: with fuse.
Included: attachable claws. Indicator LED lamp included.
Electronic cover plate code: 8530. Without fixing claws.
Operating temperature: 0 - 40 ºC.
8130.1 2CLA813010A1001 1 Cover plate code: 8562. 11
8162.1 2CLA816210A1001 1
Universal double relay time delayed switch
Rated voltage: 230 V~ ; ± 10% - 50 Hz.
For switching incandescent lamps, 230 V tungsten Cover plate for timer switch
halogen lamps, fluorescent lamps and low-voltage Cover plate for timer switch code: 8162.1.
halogen lamps, that are actuated via transformers.
3 wire connection (neutral conductor required).
With operating mode switch for operating mode: switch,
time switch.
Switch operating mode: press on the upper rocker switch Soft White 8562 BL 2CLA856200A1101 1
half to switch the light on, press on the lower rocker Silver 8562 PL 2CLA856200A1301 1
switch half to switch the light off.
Time switch operating mode: press on the upper rocker Soft Black 8562 NS 2CLA856200A1501 1
switch half to switch the light on, the light automatically Stainless Steel 8562 AI 2CLA856200A1401 1
switches off after a time delay. Manual switching off not
possible. The delay can be set in 5 steps between 30 and Antique Gold 8562 OE 2CLA856200A1201 1
300 secs.
Operation also possible via conventional push buttons
8104.X.
Inputs: 1.
Polling voltage: 230 V~, Sensing pulse, L-wire.
Outputs: 2 Normally open contacts, potential-bound.
Suitable for: ohmic, capacitive and inductive loads.
Rated current: 2x 3 AX.
Rated power: 2x 700 W / VA.
Included: attachable claws.
Electronic cover plate code: 8530.
8130.2 2CLA813020A1001 1
