Page 1538 - Din prodcuts 2020

11/432 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Zenit
Socket outlets

Color Article-No. Order-No. Pack/Qty Color Article-No. Order-No. Pack/Qty

Schuko socket outlet - 2M French/Earth-pin socket outlet - 2M
Rated voltage: 250 Vac. Rated voltage: 250 Vac.
Rated current: 16A. Rated current: 16A.
Type F: 2P + E. Type E: 2P + E.
Shuttered for child safety. Shuttered for child safety.
Screw terminals. Screw terminals.

White N2288 BL 2CLA228800N1101 10 White N2287 BL 2CLA228700N1101 10
Silver N2288 PL 2CLA228800N1301 10 Silver N2287 PL 2CLA228700N1301 10
Anthracite N2288 AN 2CLA228800N1801 10 Anthracite N2287 AN 2CLA228700N1801 10
Champagne N2288 CV 2CLA228800N1901 10 Champagne N2287 CV 2CLA228700N1901 10

Schuko socket outlet - 2M French/Earth-pin socket outlet - 2M
Rated voltage: 250 Vac. Rated voltage: 250 Vac.
Rated current: 16A. Rated current: 16A.
Type F: 2P + E. Type E: 2P + E.
Shuttered for child safety. Shuttered for child safety.
Screw terminals. Screw terminals.
Suitable to identify special circuits. Suitable to identify special circuits.
Red N2288 RJ 2CLA228800N7001 5 Red N2287 RJ 2CLA228770N1001 10
Green N2288 VD 2CLA228800N8001 5
French/Earth-pin socket outlet screwless - 2M
Orange N2288 NA 2CLA228800N9001 5
Rated voltage: 250 Vac.
Rated current: 16A.
11
Schuko socket outlet with lid - 2M Type E: 2P + E.
Rated voltage: 250 Vac. Shuttered for child safety.
Rated current: 16A. Screwless terminals.
Type F: 2P + E.
Shuttered for child safety. White N2287.6 BL 2CLA228760N1101 10
Screw terminals.
Lid with notch. 180° opening. Silver N2287.6 PL 2CLA228760N1301 10
Anthracite N2287.6 AN 2CLA228760N1801 10
White N2288.1 BL 2CLA228810N1101 10 Champagne N2287.6 CV 2CLA228760N1901 10
Silver N2288.1 PL 2CLA228810N1301 10
Anthracite N2288.1 AN 2CLA228810N1801 10 French/Earth-pin socket outlet screwless - 2M
Rated voltage: 250 Vac.
Champagne N2288.1 CV 2CLA228810N1901 10 Rated current: 16A.
Type E: 2P + E.
Schuko socket outlet srewless terminal - 2M Shuttered for child safety.
Rated voltage: 250 Vac. Screwless terminals.
Rated current: 16A. Suitable to identify special circuits.
Type F: 2P + E.
Shuttered for child safety. Red N2287.6 RJ 2CLA228760N7001 10
Screwless terminals.
Green N2287.6 VD 2CLA228760N8001 10
White N2288.6 BL 2CLA228860N1101 10
Italian 10/16A socket outlet - 1M
Silver N2288.6 PL 2CLA228860N1301 10
Rated voltage: 250 Vac.
Anthracite N2288.6 AN 2CLA228860N1801 10 Rated current: 10 / 16A.
Champagne N2288.6 CV 2CLA228860N1901 10 Type L: 2P + E / P17/11.
Shuttered for child safety.
Screw terminals.
European unearthed socket outlet - 2M
Rated voltage: 250 Vac.
Rated current: 16A. White N2133 BL 2CLA213300N1101 20
Type C: 2P (non earthed). Silver N2133 PL 2CLA213300N1301 20
Shuttered for child safety. Anthracite N2133 AN 2CLA213300N1801 20
Screw terminals.
Champagne N2133 CV 2CLA213300N1901 20
White N2203 BL 2CLA220300N1101 10
Silver N2203 PL 2CLA220300N1301 10
Anthracite N2203 AN 2CLA220300N1801 10
Champagne N2203 CV 2CLA220300N1901 10
