11/676 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Movement detector
Presence detector

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Busch-Presence detector premium KNX ) ) Busch-Presence detector Corridor KNX )
1
2
12 meters 30 meters
Detection range (for mounting height 2.5 m, 3 m and 4 Detection range: rectangular.
m): circular. For mounting height of 3 m: frontal toward the detector
Seated persons Ø: max. 8 m, max. 10 m and max. 14 m. at a max. of 20 m x 3 m (at a max. of 10 m x 3 m per
Walking persons Ø: max. 10 m, max. 12 m and max. 16 m. side). Crosswise toward the detector at a max. of 30 m x
Visible height 23 mm. 3 m (max. of 15 m x 3m per side).
With 4 channels. With integrated KNX bus coupler.
For dimming/brightness of the rules to a defined value Mounting height 27 mm.
in a designated collection area. With 2 channels.
HVAC function for controlling heating and/or cooling Targeted for connection and disconnection of lights
systems and ventilation systems in the designated bands depending on the room brightness.
collection area. Regulation in response to the movement possible.
Detectors application with 2 power off stages. Using the device as presence and/or movement
Detectors application with integrated monitoring detectors.
function. Detectors application with 2 power off stages.
Constant light controller with up to two independent Detectors application with integrated monitoring
channels. function.
Constant light controller with max. 2 outputs for Constant light switch with up to two independent
dimming daylight control/rules of two rooflights in the channels.
room. Constant light switch with max. 2 outputs for
Integrated object room temperature controller. brightness-dependent switching of two light bands in
10 freely programmable IR channels (blue and/or white) the area.
Incl. 5 logic channels (logic gates, gates, delay and Ceiling mounting on suspended ceilings with spring
staircase lighting) clamps, on solid ceilings in surface-mounting boxes
Evaluation via internal brightness sensor. 6131/39-xxx(-500) or on VDE flush-mounted boxes
Weighting of up to 2 external brightness values and the with intermediate ring for VDE flush-mounted boxes

11
internal brightness sensor possible. 6131/38-xxx(-500).
The programming button can be activated with the IR Suitable for false ceilings with a board thickness from
transmitter 6010-25 (-500). 9 to 25 mm.
With integrated KNX bus coupler. Hole size: Ø 68 mm.
Suitable for false ceilings with a board thickness from Cannot be installed in British Standard or VDE
9 to 25 mm. flushmounted box.
Hole size: Ø 68 mm. Recommendation: Installation housing from Kaiser
Suitable for surface mounting installation. HaloX-O (Art.no. 1290-40) with corresponding cover
Cannot be installed in British Standard or VDE plates (1290-47 or 1290-85 for fair faced concrete) or
flushmounted box. IBTronic H120-68 from Spelsberg.
Recommendation: Installation housing from Kaiser Connections:
HaloX-O (Art.no. 1290-40) with corresponding cover KNX-line: Bus connection terminal
plates (1290-47 or 1290-85 for fair faced concrete) or Brightness limit value: 1 Lux - 1000 Lux
IBTronic H120-68 from Spelsberg. Mounting height: 2 m - 4 m
Connections: Protection class (Device): IP 20
KNX-line: Bus connection terminal Temperature range (Device): -5 °C to 45 °C
Brightness limit value: 1 Lux - 1000 Lux Dimensions: (L x W x D): 91 mm x 91 mm x 49 mm
Mounting height: 2 m - 4 m Mounting depth: 22 mm
Protection class (Device): IP 20 studio white 6131/50-24-500 2CKA006132A0399 1
Temperature range (Device): -5 °C to 45 °C matt
Dimensions: (L x W x D): 91 mm x 91 mm x 45 mm
Mounting depth: 22 mm studio white 6131/50-24-508 2CKA006131A0054 1
matt
aluminium 6131/31-183-500 2CKA006132A0349 1
silver aluminium 6131/50-183-500 2CKA006132A0400 1
silver
studio white 6131/31-24-500 2CKA006132A0348 1
matt 1) For software and description please check the current Online-Catalogue.
1) For software and description please check the current Online-Catalogue.
2) HVAC = Heating/ ventilation/air-conditioning
