ABB i-bus® KNX
Shading Control

Blind/Roller Shutter Actuator, 230 V AC, MDRC
For the control of independent 230 V AC drives via ABB i-bus® KNX. The devices are designed
for positioning blinds, roller shutters, awnings and other shading products as well as for
controlling doors, windows and ventilation flaps. Additional auxiliary voltage is not needed.
To protect the drives, the output contacts are electromechanically locked against each other.

Description Mod. Order details Price Weight Pack
JRA/S 2.230.1.1 width 1 piece 1 piece unit
Type code Order code kg pc.
2-fold 4 JRA/S 2.230.1.1 2CDG110129R0011 0.21 1
4-fold 4 JRA/S 4.230.1.1 2CDG110130R0011 0.25 1
8-fold 8 JRA/S 8.230.1.1 2CDG110131R0011 0.46 1

Blind/Roller Shutter Actuator with Binary Inputs, 6-fold, 230 V, MDRC
For the control of 6 independent Blind/ Roller drives or air dampers. Via the 12 binary input
a direct operation of the outputs is possible with conventional switch sensors. The binary in-
puts may also be used for other operations (e.g. switching, dimming). To protect the drives,
the output contacts are electromechanically locked against each other.

JRA/S 6.230.3.1 Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
12 JRA/S 6.230.3.1 2CDG110208R0011 0.55 1

Shutter Actuator, 1-fold, FM
For controlling blind or awning motors. With 3 inputs and 1 change-over output – normally
open contact, potential-bound –. Rated voltage: 230 V~, +10% / – 10%, 50 Hz – 60 Hz. Input
polling voltage: 5 V. Output rated current: 3 A, cos φ 0.8, Output voltage: 250 V~.
The bus can be connected via enclosed terminal block. 14

6152/11 U-500 Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– 6152/11 U-500 2CKA006152A0040 0.11 1

Combi Actuator, FM
For controlling blind or awning motors. For connecting thermoelectric actuating drives.
With 3 inputs and 2 outputs. A first output (O1) allows the control of electrically-operated
Venetian blinds, roller shutters, awnings, venting louvers or similar blinds for 230 V AC
mains voltage. One additional electronic switching output (O2) allows silent control of
electrothermal valve drives for heating or cooling systems. The bus can be connected via
6173/11 U-500 enclosed terminal block. Rated voltage: 230 V~, +10% / –10%, 50 Hz – 60 Hz. Input polling
voltage 5V. O1 Rated current 3 A, cos φ 0.8; Output voltage: 250 V~. O2: Rated current: 25 mA,
cos φ 1, Output voltage: 250 V~.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– 6173/11 U-500 2CKA006151A0249 0.11 1
