          ABB i-bus® KNX
          Lighting Control – DALI




          DALI Gateway DG/S 8.1
          The proven technology























          Lighting groups are formed via “rigid” hardware wiring.
          Fast commissioning as no addressing is necessary.
          No readdressing when a ballast is exchanged. 8 x 16 DALI
          devices.



              Fixed connection
                                   DALI



                         DALI


                         DALI
  14
                             1 23 456 78
                             DALI Gateway
                              DG/S 8.1

           KNX

                     Manual             Operation/
                light operation         visualisation
                                        via touch display
