14/52 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB i-bus® KNX
Shading Control

SMI Shutter Actuator with Manual Operation, 4-fold, MDRC
It controls four independent groups (broadcast) with up to four SMI (Standard Motor Inter-
face) drives (230 V) for positioning blinds, roller shutters, awnings and other shading prod-
ucts. Status signals (motor fault, direction of movement) can also be sent from the SMI drive
on the bus. Push buttons are located at the front of the device to control the outputs e.g.
during commissioning. The current status of the output is displayed via LEDs.

Description Mod. Order details Price Weight Pack
JA/S 4.SMI.1M width 1 piece 1 piece unit
Type code Order code kg pc.
4 JA/S 4.SMI.1M 2CDG110028R0011 0.25 1

SMI Blind/Roller Shutter Actuator, 4-fold, LoVo, MDRC
It controls four independent groups (broadcast) with up to four SMI (Standard Motor Inter-
face) LoVo drives for positioning blinds, roller shutters, awnings and other shading prod-
ucts. Status signals (motor fault, direction of movement) can also be sent from the SMI drive
on the bus. Push buttons are located at the front of the device to control the outputs
e.g. during commissioning. The current status of the output is displayed via LEDs.

Description Mod. Order details Price Weight Pack
SJR/S 4.24.2.1 width 1 piece 1 piece unit
Type code Order code kg pc.
4 SJR/S 4.24.2.1 2CDG110143R0011 0.25 1

Shutter Control Unit, MDRC
Controls shutter and blind actuators according to the position of the sun. The shutter con-
trol unit contains the functions of anti-glare protection and daylight redirection for up to
4 facades. Automatic shading can be implemented for every building and climatic control
can be supported by the comprehensive range of parameter settings in the ETS.
14
Description Mod. Order details Price Weight Pack
JSB/S 1.1 width 1 piece 1 piece unit
Type code Order code kg pc.
2 JSB/S 1.1 GHQ6310084R0111 0.12 1
